TPS71202-EP Series

Enhanced product, 250-mA dual-output, ultra-low noise, high PSRR, low-dropout linear regular

Catalog

Enhanced product, 250-mA dual-output, ultra-low noise, high PSRR, low-dropout linear regular

Part	Output Type	Current - Supply (Max) [Max]	Voltage - Output (Min/Fixed)	Output Configuration	Protection Features	Number of Regulators	Voltage - Input (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Current - Output	Package / Case	Supplier Device Package	PSRR [Min]	PSRR [Max]	Control Features	Voltage Dropout (Max) [Max]	Voltage - Output (Max) [Max]	Output Type	Voltage - Output (Min/Fixed)	Regulator Type	Channels per IC	Voltage - Input [Min]	Voltage - Input [Max]	Supplied Contents	Utilized IC / Part	Board Type	Voltage - Output
Texas Instruments TPS71247DRCT	1.81 mOhm	600 µA	1.8 V 2.85 V	Positive	Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	2	5.5 V	125 °C	-40 °C	Surface Mount	250 mA	10-VFDFN Exposed Pad	10-VSON (3x3)	54 dB	59 dB	Enable Power Good	0.4 V
Texas Instruments TPS71257DRCR	1.81 mOhm	600 µA	2.85 V	Positive	Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	2	5.5 V	125 °C	-40 °C	Surface Mount	250 mA	10-VFDFN Exposed Pad	10-VSON (3x3)	54 dB	59 dB	Enable Power Good	0.4 V
Texas Instruments TPS71202DRCTG4		600 µA	1.2 V	Positive	Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	2	5.5 V	125 °C	-40 °C	Surface Mount	250 mA	10-VFDFN Exposed Pad	10-VSON (3x3)	54 dB	59 dB	Enable Power Good	0.4 V	5.5 V	Adjustable
Texas Instruments TPS71202DRCT		600 µA	1.2 V	Positive	Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	2	5.5 V	125 °C	-40 °C	Surface Mount	250 mA	10-VFDFN Exposed Pad	10-VSON (3x3)	54 dB	59 dB	Enable Power Good	0.4 V	5.5 V	Adjustable
Texas Instruments TPS71229DRCR		600 µA	1.2 V	Positive	Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	2	5.5 V	125 °C	-40 °C	Surface Mount	250 mA	10-VFDFN Exposed Pad	10-VSON (3x3)	54 dB	59 dB	Enable Power Good	0.4 V	5.5 V	Adjustable (Fixed)	2.8 V
Texas Instruments TPS71257DRCT	1.81 mOhm	600 µA	2.85 V	Positive	Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	2	5.5 V	125 °C	-40 °C	Surface Mount	250 mA	10-VFDFN Exposed Pad	10-VSON (3x3)	54 dB	59 dB	Enable Power Good	0.4 V
Texas Instruments TPS71219DRCR		600 µA	1.2 V	Positive	Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	2	5.5 V	125 °C	-40 °C	Surface Mount	250 mA	10-VFDFN Exposed Pad	10-VSON (3x3)	54 dB	59 dB	Enable Power Good	0.4 V	5.5 V	Adjustable (Fixed)	1.8 V
Texas Instruments TPS712XXEVM-050											250 mA										Positive Fixed and Adjustable	2 - Dual	2.7 V	5.5 V	Board(s)	TPS71202 TPS71247	Fully Populated	1.225 V 1.8 V 2.8 V 2.85 V
Texas Instruments TPS71202MDRCTEP		600 µA	1.2 V	Positive	Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	2	5.5 V	125 °C	-40 °C	Surface Mount	250 mA	10-VFDFN Exposed Pad	10-VSON (3x3)	54 dB	59 dB	Enable Power Good	0.4 V	5.5 V	Adjustable
Texas Instruments TPS71219DRCRG4		600 µA	1.2 V	Positive	Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	2	5.5 V	125 °C	-40 °C	Surface Mount	250 mA	10-VFDFN Exposed Pad	10-VSON (3x3)	54 dB	59 dB	Enable Power Good	0.4 V	5.5 V	Adjustable (Fixed)	1.8 V

Catalog

Enhanced product, 250-mA dual-output, ultra-low noise, high PSRR, low-dropout linear regular

Key Features

• Dual 250-mA High-Performance RF LDOsAdjustable Output Voltage (1.2 V to 5.5 V)High PSRR: 65 dB at 10 kHzUltra-Low Noise: 32 µVrmsFast Start-Up Time: 60 µsStable with 2.2-µF Ceramic CapacitorExcellent Load/Line Transient ResponseVery Low Dropout Voltage: 125 mV at 250 mAIndependent Enable PinsThermal Shutdown and Independent Current LimitAvailable in Thermally-Enhanced SON Package: 3 mm × 3 mm × 1 mmAPPLICATIONSCellular and Cordless PhonesWireless PDA/Handheld ProductsPCMCIA/Wireless LAN ApplicationsDigital Camera/Camcorder/Internet AudioDSP/FPGA/ASIC/Controllers and ProcessorsSUPPORTS DEFENSE, AEROSPACE, AND MEDICAL APPLICATIONSControlled BaselineOne Assembly/Test SiteOne Fabrication SiteAvailable in Military (–55°C/125°C) Temperature Range(1)Extended Product Life CycleExtended Product-Change NotificationProduct Traceability(1)Custom temperature ranges availableDual 250-mA High-Performance RF LDOsAdjustable Output Voltage (1.2 V to 5.5 V)High PSRR: 65 dB at 10 kHzUltra-Low Noise: 32 µVrmsFast Start-Up Time: 60 µsStable with 2.2-µF Ceramic CapacitorExcellent Load/Line Transient ResponseVery Low Dropout Voltage: 125 mV at 250 mAIndependent Enable PinsThermal Shutdown and Independent Current LimitAvailable in Thermally-Enhanced SON Package: 3 mm × 3 mm × 1 mmAPPLICATIONSCellular and Cordless PhonesWireless PDA/Handheld ProductsPCMCIA/Wireless LAN ApplicationsDigital Camera/Camcorder/Internet AudioDSP/FPGA/ASIC/Controllers and ProcessorsSUPPORTS DEFENSE, AEROSPACE, AND MEDICAL APPLICATIONSControlled BaselineOne Assembly/Test SiteOne Fabrication SiteAvailable in Military (–55°C/125°C) Temperature Range(1)Extended Product Life CycleExtended Product-Change NotificationProduct Traceability(1)Custom temperature ranges available

Description

The TPS712xx family of low-dropout (LDO) voltage regulators is tailored to noise-sensitive and RF applications. These products feature dual 250 mA LDOs with ultralow noise, high power-supply rejection ratio (PSRR), and fast transient and start-up response. Each regulator output is stable with low-cost 2.2 µF ceramic output capacitors and features very low dropout voltages (125 mV typical at 250 mA). Each regulator achieves fast start-up times (approximately 60 µs with a 0.001 µF bypass capacitor) while consuming very low quiescent current (300 µA typical with both outputs enabled). When the device is placed in standby mode, the supply current is reduced to less than 0.3 µA typical. Each regulator exhibits approximately 32 µrms of output voltage noise with VOUT= 2.8 V and a 0.01 µF noise reduction (NR) capacitor. Applications with analog components that are noise-sensitive, such as portable RF electronics, will benefit from high PSRR, low noise, and fast line and load transient features. The TPS712 family is offered in a thin 3mm × 3mm SON package and is fully specified from –40°C to +125°C (TJ). The TPS712xx family of low-dropout (LDO) voltage regulators is tailored to noise-sensitive and RF applications. These products feature dual 250 mA LDOs with ultralow noise, high power-supply rejection ratio (PSRR), and fast transient and start-up response. Each regulator output is stable with low-cost 2.2 µF ceramic output capacitors and features very low dropout voltages (125 mV typical at 250 mA). Each regulator achieves fast start-up times (approximately 60 µs with a 0.001 µF bypass capacitor) while consuming very low quiescent current (300 µA typical with both outputs enabled). When the device is placed in standby mode, the supply current is reduced to less than 0.3 µA typical. Each regulator exhibits approximately 32 µrms of output voltage noise with VOUT= 2.8 V and a 0.01 µF noise reduction (NR) capacitor. Applications with analog components that are noise-sensitive, such as portable RF electronics, will benefit from high PSRR, low noise, and fast line and load transient features. The TPS712 family is offered in a thin 3mm × 3mm SON package and is fully specified from –40°C to +125°C (TJ).
