VX7815 Series

Manufacturer: CUI Inc.

Catalog

DC DC CONVERTER +/-15V 20W

Part	Applications	Type	Number of Outputs	Mounting Type	Efficiency	Power (Watts)	Package / Case	Current - Output (Max)	Approval Agency	Voltage - Input (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Standard Number	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Voltage - Output 1	Voltage - Input (Min) [Min]	Voltage - Output 2	Current - Output (Max) [Max]	Size / Dimension [z]	Size / Dimension [y]
CUI Inc. VX7815-1000R	ITE (Commercial)	Non-Isolated PoL Module	1	Right Angle Through Hole	96 %	20 W	3-SIP Module	1 A 300 mA	CB Scheme EN IEC UL	36 V	-40 °C	85 °C	55024 55032 Class A 60950-1	11.5 mm	0.35 in	0.45 in	0.69 in	9 mm	17.5 mm	-15 V 15 V	8 V	-15 V
CUI Inc. VX7815-1000	ITE (Commercial)	Linear Regulator Replacement	1	Through Hole	96 %	15 W	3-SIP Module		CB Scheme EN IEC UL	36 V	-40 °C	85 °C	55024 55032 Class A 60950-1	9 mm	0.69 in	0.35 in	0.45 "	17.5 mm	11.5 mm	15 V	20 V		1 A
CUI Inc. VX7815-500	ITE (Commercial)	Linear Regulator Replacement	1	Through Hole	95 %	7.5 W	3-SIP Module		CB Scheme EN IEC UL	36 V	-40 °C	85 °C	55024 55032 Class A 60950-1		0.4 "	0.3 "	0.46 in		11.6 mm	15 V	19 V		500 mA	10.2 mm	7.6 mm
