306-027 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 54POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Rows [custom] | Flange Feature | Contact Finish | Number of Positions | Contact Material | Color | Gender | Mounting Type | Contact Type | Read Out | Card Thickness [Max] | Card Thickness [Min] | Card Type | Number of Positions/Bay/Row | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | Flush Mount M3 Threaded Insert Top Opening | Tin | 54 | Copper Alloy | Green | Female | Panel Mount Through Hole | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder | 3.96 mm | 0.156 in | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | Gold | 54 | Copper Alloy | Green | Female | Through Hole | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | Floating Bobbin Flush Mount | Gold | 54 | Copper Alloy | Green | Female | Panel Mount Through Hole | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 54 | Copper Alloy | Green | Female | Panel Mount Through Hole | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | Flush Mount M3 Threaded Insert Top Opening | Gold | 54 | Copper Alloy | Green | Female | Panel Mount Through Hole | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Tin | 54 | Copper Alloy | Green | Female | Panel Mount Through Hole | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder | 3.96 mm | 0.156 in | Card Guides | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 54 | Copper Alloy | Green | Female | Panel Mount | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder Eyelet(s) | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Tin | 54 | Copper Alloy | Green | Female | Panel Mount | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder Eyelet(s) | 3.96 mm | 0.156 in | Card Guides | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Tin | 54 | Copper Alloy | Green | Female | Panel Mount | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder Eyelet(s) | 3.96 mm | 0.156 in | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 54 | Copper Alloy | Green | Female | Panel Mount Through Hole | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 27 | -40 C | 105 ░C | Solder | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Card Guides |
