SLA50 Series
Manufacturer: Sanken Electric USA Inc.
Beta
⌘K
MOSFET 4N-CH 60V 7A 15SIP
| Part | Mounting Type | Input Capacitance (Ciss) (Max) @ Vds [Max] | Technology | Vgs(th) (Max) @ Id | Current - Continuous Drain (Id) @ 25°C | Package / Case | Configuration | Power - Max [Max] | Operating Temperature | Supplier Device Package | Drain to Source Voltage (Vdss) | Rds On (Max) @ Id, Vgs | FET Feature | Current - Continuous Drain (Id) @ 25°C [Min] | Current - Continuous Drain (Id) @ 25°C [Max] | Rds On (Max) @ Id, Vgs [Max] | Voltage - Rated | Transistor Type | Applications | Current Rating (Amps) | Input Capacitance (Ciss) (Max) @ Vds |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sanken Electric USA Inc. | Through Hole | 660 pF | MOSFET (Metal Oxide) | 2 V | 7 A | 15-SIP | 4 N-Channel | 4.8 W | 150 °C | 15-SIP | 60 V | ||||||||||
 Sanken Electric USA Inc. | Through Hole | 1630 pF | MOSFET (Metal Oxide) | 2 V | 10 A | 12-SIP Exposed Tab | 4 N-Channel | 5 W | 150 °C | 12-SIP | 100 V | 80 mOhm | Logic Level Gate | ||||||||
 Sanken Electric USA Inc. | Through Hole | 660 pF | MOSFET (Metal Oxide) | 2 V | 7 A | 15-SIP Exposed Tab Formed Leads | 4 N-Channel | 4.8 W | 150 °C | 15-ZIP | 60 V | ||||||||||
 Sanken Electric USA Inc. | Through Hole | 660 pF | MOSFET (Metal Oxide) | 2 V | 7 A | 15-SIP Exposed Tab Formed Leads | 6 N-Channel (3-Phase Bridge) | 5 W | 150 °C | 15-ZIP | 60 V | ||||||||||
Sanken Electric USA Inc. | Through Hole | 460 pF 1200 pF | MOSFET (Metal Oxide) | 12-SIP Exposed Tab | 3 N and 3 P-Channel (3-Phase Bridge) | 5 W | 150 °C | 12-SIP | 60 V | Logic Level Gate | 6 A | 10 A | |||||||||
Sanken Electric USA Inc. | Through Hole | 460 pF 1200 pF | MOSFET (Metal Oxide) | 10 A | 12-SIP Exposed Tab | 3 N and 3 P-Channel (3-Phase Bridge) | 5 W | 150 °C | 12-SIP | 60 V | Logic Level Gate | ||||||||||
Sanken Electric USA Inc. | Through Hole | 850 pF | MOSFET (Metal Oxide) | 10 A | 12-SIP Exposed Tab | 4 N-Channel | 5 W | 150 °C | 12-SIP | 200 V | Logic Level Gate | 175 mOhm | |||||||||
 Sanken Electric USA Inc. | Through Hole | MOSFET (Metal Oxide) | 8 A | 15-SIP Exposed Tab Formed Leads | 3 N and 3 P-Channel (3-Phase Bridge) | 15-ZIP | 55 V | ||||||||||||||
Sanken Electric USA Inc. | Through Hole | 12-SIP Exposed Tab | 12-SIP | 60 VDC | 3 N-Channel 3 PNP Darlington | General Purpose | 6 A | ||||||||||||||
Sanken Electric USA Inc. | Through Hole | MOSFET (Metal Oxide) | 2 V | 4 A | 12-SIP Exposed Tab | 3 N and 3 P-Channel (3-Phase Bridge) | 5 W | 150 °C | 12-SIP | 60 V | 550 mOhm | Logic Level Gate | 150 pF 320 pF |
