ACPL-177 Series

Catalog

LOGIC OUTPUT OPTOCOUPLERS 3.3V 4CH 1500VDC HERMETICALLY SEALED

Part	Supplier Device Package	Current Transfer Ratio (Min)	Current - DC Forward (If) (Max) [Max]	Turn On / Turn Off Time (Typ)	Output Type	Input Type	Number of Channels [custom]	Voltage - Forward (Vf) (Typ)	Voltage - Isolation	Current - Output / Channel	Package / Case	Voltage - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type
Broadcom Limited ACPL-177KL	16-CDIP	200 %	10 mA	2 µs 6 µs	Darlington	DC	4	1.4 V	1.5 kV	40 mA	16-CDIP (0.300" 7.62mm)	20 V	-55 C	125 °C	Through Hole
Broadcom Limited ACPL-177KL-300	16-DIP Gull Wing	200 %	10 mA	2 µs 6 µs	Darlington	DC	4	1.4 V	1.5 kV	40 mA	16-SMD Gull Wing	20 V	-55 C	125 °C	Surface Mount
Broadcom Limited ACPL-177KL-100	16-DIP Butt Joint	200 %	10 mA	2 µs 6 µs	Darlington	DC	4	1.4 V	1.5 kV	40 mA	16-SMD Butt Joint	20 V	-55 C	125 °C	Surface Mount
Broadcom Limited ACPL-177KL-200	16-CDIP	200 %	10 mA	2 µs 6 µs	Darlington	DC	4	1.4 V	1.5 kV	40 mA	16-CDIP (0.300" 7.62mm)	20 V	-55 C	125 °C	Through Hole
