307-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 21POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Gender | Number of Rows | Read Out | Termination | Card Type | Contact Material | Color | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Contact Finish | Contact Type | Number of Positions/Bay/Row [custom] | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 21 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | 1 | Single | Wire Wrap | Non Specified - Single Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | Through Hole | Gold | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 42 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | Dual | Solder | Non Specified - Dual Edge | Copper Alloy | Green | Through Hole | Tin | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 21 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | 1 | Single | Solder | Non Specified - Single Edge | Copper Alloy | Green | Through Hole | Tin | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 42 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | Dual | Wire Wrap | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | Right Angle Through Hole | Gold | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 42 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | Dual | Solder Eyelet(s) | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | Surface Mount | Gold | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 42 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | Dual | Solder Eyelet(s) | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | Through Hole | Gold | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 21 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | 1 | Single | Solder | Non Specified - Single Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | Through Hole | Gold | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 21 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | 1 | Single | Solder Eyelet(s) | Non Specified - Single Edge | Copper Alloy | Green | Through Hole | Tin | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 42 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | Dual | Solder Eyelet(s) | Non Specified - Dual Edge | Copper Alloy | Green | Through Hole | Tin | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 21 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Female | 1 | Single | Wire Wrap | Non Specified - Single Edge | Copper Alloy | Green | Through Hole | Tin | Semi Bellows | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm |
