887-006 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 6POS 0.156
| Part | Material - Insulation | Termination Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Number of Rows | Mounting Type | Contact Material | Contact Finish | Gender | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Color | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Card Type | Termination | Read Out |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 3.96 mm | 0.156 in | 1 | Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Solder Eyelet(s) | Single |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | 1 | Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Solder Eyelet(s) | Single |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | 1 | Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Solder Eyelet(s) | Single |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | 1 | Right Angle Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Solder | Single |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | 1 | Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Wire Wrap | Single | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | M3 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | 1 | Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Solder | Single | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 4-40 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | 1 | Right Angle Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Solder | Single | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 4-40 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | 1 | Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Wire Wrap | Single | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | 1 | Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Solder | Single | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | 1 | Through Hole | Copper Alloy | Gold | Female | 6 | 125 °C | -40 C | 6 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Solder | Single |
