280377 Series

Catalog

CONN HEADER R/A 2POS 2.54MM

Part	Shrouding	Style	Number of Rows	Insulation Color	Contact Finish - Mating	Number of Positions	Contact Length - Mating [custom]	Contact Length - Mating [custom]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Fastening Type	Mounting Type	Current Rating (Amps)	Insulation Material	Pitch - Mating	Pitch - Mating	Contact Length - Post	Contact Length - Post	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions Loaded	Material Flammability Rating	Contact Finish - Post	Insulation Height	Insulation Height	Voltage Rating	Contact Shape	Connector Type	Contact Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Type	Contact Finish Thickness - Post	Contact Finish Thickness - Mating
TE Connectivity Raychem Cable Protection 280377-3	Shrouded - 3 Wall	Board to Board Cable	1	Black	Gold	2	6.6 mm	0.26 in	31.5 µin	0.8 µm	Detent Lock	Through Hole Right Angle	3 A	Thermoplastic	0.1 in	2.54 mm	3.5 mm	0.138 in	Solder	-40 °C	80 C	All	UL94 V-0	Tin	0.197 in	5 mm	40 V	Square	Header	Brass	2.5 µm	98.4 µin	Male Pin
TE Connectivity Raychem Cable Protection 280377-1	Shrouded - 3 Wall	Board to Board Cable	1	Black		2	6.6 mm	0.26 in		118.1 µin	Detent Lock	Through Hole Right Angle	3 A	Thermoplastic	0.1 in	2.54 mm	3.5 mm	0.138 in	Solder	-40 °C	80 C	All	UL94 V-0	Tin	0.197 in	5 mm	40 V	Square	Header	Brass		3 µm	Male Pin	118.1 µin	3 µm
