FPASF Series
Manufacturer: Fraenkische USA, LP
Beta
⌘K
FIPLOCK, PA6 MOD BS, NW23, FINE,
| Part | Features | Type Attributes | Length | Length | Material | Operating Temperature [Max] | Operating Temperature [Min] | Color | Environment Protection | Diameter - Outside [diameter] | Diameter - Outside [diameter] | Diameter - Inside [diameter] | Diameter - Inside [diameter] | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 50 m | 164 ft | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Black | Weather Resistant | 28.4 mm | 1.118 in | 0.89 in | 22.6 mm | Wire Loom Protective Hose |
Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 50 m | 164 ft | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Black | Weather Resistant | 10 mm | 0.394 in | 0.244 in | 6.2 mm | Wire Loom Protective Hose |
Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 50 m | 164 ft | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Black | Weather Resistant | 12.8 mm | 0.504 " | 0.378 " | 9.6 mm | Wire Loom Protective Hose |
Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 25 m | 82.02 ' | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Gray | Weather Resistant | 54.4 mm | 2.142 in | 1.87 " | 47.5 mm | Wire Loom Protective Hose |
Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 50 m | 164 ft | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Black | Weather Resistant | 34.49 mm | 1.358 in | 1.142 in | 29 mm | Wire Loom Protective Hose |
Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 50 m | 164 ft | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Gray | Weather Resistant | 15.7 mm | 0.618 in | 0.472 in | 12 mm | Wire Loom Protective Hose |
Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 25 m | 82.02 ' | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Gray | Weather Resistant | 42.4 mm | 1.669 in | 1.437 in | 36.5 mm | Wire Loom Protective Hose |
Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 25 m | 82.02 ' | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Black | Weather Resistant | 54.4 mm | 2.142 in | 1.87 " | 47.5 mm | Wire Loom Protective Hose |
Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 50 m | 164 ft | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Gray | Weather Resistant | 10 mm | 0.394 in | 0.244 in | 6.2 mm | Wire Loom Protective Hose |
Fraenkische USA, LP | Chemical Resistant Impact Resistant | Convoluted Corrugated | 50 m | 164 ft | Polyamide (PA6) Nylon 6 Halogen Free | 120 °C | -45 °C | Gray | Weather Resistant | 12.8 mm | 0.504 " | 0.378 " | 9.6 mm | Wire Loom Protective Hose |
