74HC4052 Series

Catalog

LOG CMOS MLTIPLEXER DUAL

Part	Multiplexer/Demultiplexer Circuit	Voltage - Supply, Dual (V±) [Min]	Voltage - Supply, Dual (V±) [Max]	-3db Bandwidth	Mounting Type	Crosstalk	Operating Temperature [Max]	Operating Temperature [Min]	Number of Circuits	Channel-to-Channel Matching (ΔRon)	On-State Resistance (Max) [Max]	Current - Leakage (IS(off)) (Max) [Max]	Package / Case [x]	Package / Case	Package / Case [y]	Voltage - Supply, Single (V+) [Min]	Voltage - Supply, Single (V+) [Max]	Switch Circuit	Channel Capacitance (CS(off), CD(off)) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	Supplier Device Package	Switch Time (Ton, Toff) (Max) [custom]	Switch Time (Ton, Toff) (Max) [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case
ON Semiconductor MC74HC4052FEL
ON Semiconductor MC74HC4052ADT	4:1	-2 V	6 V	95 MHz	Surface Mount	-60 dB	125 °C	-55 °C	2	10 Ohm	100 Ohms	100 nA	0.173 in	16-TSSOP	4.4 mm	2 V	6 V	SP4T	80 pF	80 pF	16-TSSOP
ON Semiconductor MM74HC4052WM	4:1	-2 V	6 V	35 MHz	Surface Mount	-50 dB			2	15 Ohm	100 Ohms	100 nA	0.295 in	16-SOIC	7.5 mm	2 V	6 V	SP4T	5 pF	45 pF	16-SOIC	41 ns	32 ns	85 °C	-40 °C
ON Semiconductor MC74HC4052FR1
ON Semiconductor MM74HC4052SJ	4:1	-2 V	6 V	35 MHz	Surface Mount	-50 dB			2	15 Ohm	100 Ohms	100 nA		16-SOIC		2 V	6 V	SP4T	5 pF	45 pF	16-SOP	41 ns	32 ns	85 °C	-40 °C	0.209 "	5.3 mm
ON Semiconductor MC74HC4052ADW	4:1	-2 V	6 V	95 MHz	Surface Mount	-60 dB	125 °C	-55 °C	2	10 Ohm	100 Ohms	100 nA	0.295 in	16-SOIC	7.5 mm	2 V	6 V	SP4T	80 pF	80 pF	16-SOIC
ON Semiconductor MM74HC4052M	4:1	-2 V	6 V	35 MHz	Surface Mount	-50 dB			2	15 Ohm	100 Ohms	100 nA	0.154 in	16-SOIC	3.9 mm	2 V	6 V	SP4T	5 pF	45 pF	16-SOIC	41 ns	32 ns	85 °C	-40 °C
ON Semiconductor MM74HC4052SJX	4:1	-2 V	6 V	35 MHz	Surface Mount	-50 dB			2	15 Ohm	100 Ohms	100 nA		16-SOIC		2 V	6 V	SP4T	5 pF	45 pF	16-SOP	41 ns	32 ns	85 °C	-40 °C	0.209 "	5.3 mm
ON Semiconductor MC74HC4052ADWR2G	4:1	-2 V	6 V	95 MHz	Surface Mount	-60 dB	125 °C	-55 °C	2	10 Ohm	100 Ohms	100 nA	0.295 in	16-SOIC	7.5 mm	2 V	6 V	SP4T	80 pF	80 pF	16-SOIC
ON Semiconductor MC74HC4052AD	4:1	-2 V	6 V	95 MHz	Surface Mount	-60 dB	125 °C	-55 °C	2	10 Ohm	100 Ohms	100 nA	0.154 in	16-SOIC	3.9 mm	2 V	6 V	SP4T	80 pF	80 pF	16-SOIC
