087754 Series
Manufacturer: Molex
Beta
⌘K
CONN HEADER R/A 5POS 2MM
| Part | Applications | Insulation Material | Contact Finish - Post | Contact Type | Fastening Type | Style | Connector Type | Contact Length - Mating | Contact Length - Mating | Termination | Mounting Type | Number of Positions Loaded | Contact Length - Post | Contact Length - Post | Insulation Height | Insulation Height | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Color | Contact Material | Shrouding | Material Flammability Rating | Contact Shape | Number of Rows | Pitch - Mating [x] | Pitch - Mating [x] | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Automotive General Purpose Telecommunications | Glass Filled Nylon Polyamide (PA) | Tin | Male Pin | Push-Pull | Board to Cable/Wire | Breakaway Header | 4 mm | 0.157 in | Solder | Through Hole Right Angle | All | 0.102 in | 2.6 mm | 0.079 in | 2 mm | Gold | 15 µin | 0.38 µm | Black | Copper Alloy | Unshrouded | UL94 V-0 | Square | 1 | 0.079 in | 2 mm | |
 Molex | Automotive General Purpose Telecommunications | Glass Filled Nylon Polyamide (PA) | Tin | Male Pin | Push-Pull | Board to Cable/Wire | Breakaway Header | 7.19 mm | 0.283 in | Solder | Through Hole Right Angle | All | 0.118 in | 3 mm | 0.079 in | 2 mm | 78.7 µin | 2 µm | Black | Copper Alloy | Unshrouded | UL94 V-0 | Square | 1 | 0.079 in | 2 mm | 4 |
