3057/1 Series

Catalog

WIRE, HOOK UP, UL1007/UL1569, SOLID TINNED COPPER, PVC, GRAY, 16 AWG, 100 FT

Part	Voltage	Operating Temperature [Min]	Operating Temperature [Max]	Features	Ratings	Jacket (Insulation) Material	Wire Gauge	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Conductor Strand	Conductor Material	Cable Type	Length [x]	Length [x]	Length	Length
ALPHA WIRE 3057/1 SL005	300 V	-40 °C	105 ░C	Biological Compatibility	ISO 10993 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	16 AWG	0.016 in	0.41 mm	0.083 "	2.11 mm	Slate	Solid	Copper Tinned	Hook-Up	30.5 m	100 ft
ALPHA WIRE 3057/1 OR001	300 V	-40 °C	105 ░C	Biological Compatibility	ISO 10993 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	16 AWG	0.016 in	0.41 mm	0.083 "	2.11 mm	Orange	Solid	Copper Tinned	Hook-Up			1000 ft	304.8 m
ALPHA WIRE 3057/1 BL001	300 V	-40 °C	105 ░C	Biological Compatibility	ISO 10993 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	16 AWG	0.016 in	0.41 mm	0.083 "	2.11 mm	Blue	Solid	Copper Tinned	Hook-Up			1000 ft	304.8 m
ALPHA WIRE 3057/1 SL001	300 V	-40 °C	105 ░C	Biological Compatibility	ISO 10993 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	16 AWG	0.016 in	0.41 mm	0.083 "	2.11 mm	Slate	Solid	Copper Tinned	Hook-Up			1000 ft	304.8 m
ALPHA WIRE 3057/1 BL005	300 V	-40 °C	105 ░C	Biological Compatibility	ISO 10993 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	16 AWG	0.016 in	0.41 mm	0.083 "	2.11 mm	Blue	Solid	Copper Tinned	Hook-Up	30.5 m	100 ft
ALPHA WIRE 3057/1 BK001	300 V	-40 °C	105 ░C	Biological Compatibility	ISO 10993 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	16 AWG	0.016 in	0.41 mm	0.083 "	2.11 mm	Black	Solid	Copper Tinned	Hook-Up			1000 ft	304.8 m
ALPHA WIRE 3057/1 BK005	300 V	-40 °C	105 ░C	Biological Compatibility	ISO 10993 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	16 AWG	0.016 in	0.41 mm	0.083 "	2.11 mm	Black	Solid	Copper Tinned	Hook-Up	30.5 m	100 ft
ALPHA WIRE 3057/1 BR001	300 V	-40 °C	105 ░C	Biological Compatibility	ISO 10993 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	16 AWG	0.016 in	0.41 mm	0.083 "	2.11 mm	Brown	Solid	Copper Tinned	Hook-Up			1000 ft	304.8 m
ALPHA WIRE 3057/1 GR005	300 V	-40 °C	105 ░C	Biological Compatibility	ISO 10993 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	16 AWG	0.016 in	0.41 mm	0.083 "	2.11 mm	Green	Solid	Copper Tinned	Hook-Up	30.5 m	100 ft
