415-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 41POS 0.200
| Part | Material - Insulation | Termination Rows [custom] | Contact Finish | Color | Card Type | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Number of Rows [custom] | Gender | Mounting Type | Number of Positions | Card Thickness | Card Thickness | Contact Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Green | Non Specified - Dual Edge | Wire Wrap | -65 ░C | 125 °C | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 2 | Female | Panel Mount Through Hole | 41 | 2.36 mm | 0.093 " | Copper Alloy | Card Guides |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Green | Non Specified - Dual Edge | Solder Eyelet(s) | -65 ░C | 125 °C | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 2 | Female | Panel Mount Through Hole | 41 | 2.36 mm | 0.093 " | Copper Alloy | Card Guides |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Green | Non Specified - Dual Edge | Solder | -65 ░C | 125 °C | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 2 | Female | Panel Mount Through Hole | 41 | 2.36 mm | 0.093 " | Copper Alloy | Card Guides |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Green | Non Specified - Dual Edge | Wire Wrap | -65 ░C | 125 °C | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 2 | Female | Panel Mount Through Hole | 41 | 1.57 mm | 0.062 in | Copper Alloy | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Green | Non Specified - Dual Edge | Wire Wrap | -65 ░C | 125 °C | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 2 | Female | Panel Mount Through Hole | 41 | 1.57 mm | 0.062 in | Copper Alloy | Card Guides |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Green | Non Specified - Dual Edge | Wire Wrap | -65 ░C | 125 °C | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 2 | Female | Panel Mount Through Hole | 41 | 2.36 mm | 0.093 " | Copper Alloy | Card Guides |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Green | Non Specified - Dual Edge | Wire Wrap | -65 ░C | 125 °C | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 2 | Female | Panel Mount Through Hole | 41 | 2.36 mm | 0.093 " | Copper Alloy | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Green | Non Specified - Dual Edge | Solder | -65 ░C | 125 °C | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 2 | Female | Panel Mount Through Hole | 41 | 1.57 mm | 0.062 in | Copper Alloy | Card Guides |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Green | Non Specified - Dual Edge | Wire Wrap | -65 ░C | 125 °C | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 2 | Female | Panel Mount Through Hole | 41 | 1.57 mm | 0.062 in | Copper Alloy | Card Guides |
