FD4D096 Series
Manufacturer: Belden Inc.
Beta
⌘K
CBL FIBER OPTIC 125UM MULTIMODE
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Tensile Strength | Jacket (Insulation) Material | Cladding Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Type | Ratings | Style | Features | Features | Jacket Color | Core Diameter [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 70 °C | -40 C | 81.6 kg | Poly-Vinyl Chloride (PVC) | 125 µm | 1.39 in | 35.31 mm | Multimode | OFCR | Multiple Fibers | Armored | 96 Fibers | Black | 50 µm |
 Belden Inc. | 70 °C | -40 C | 81.6 kg | Low Smoke Zero Halogen (LSZH) | 125 µm | 0.977 in | 24.82 mm | Multimode | OFNR | Multiple Fibers | 96 Fibers Rip Cord | Black | 50 µm | |
 Belden Inc. | 70 °C | -40 C | 81.6 kg | Poly-Vinyl Chloride (PVC) | 125 µm | 0.9 " | 22.86 mm | Multimode | OFNP | Multiple Fibers | 96 Fibers Rip Cord | Black | 50 µm | |
 Belden Inc. | 70 °C | -40 C | 81.6 kg | Poly-Vinyl Chloride (PVC) | 125 µm | 1.26 in | 32 mm | Multimode | OFCP | Multiple Fibers | Armored | 96 Fibers | Black | 50 µm |
Belden Inc. | 70 °C | -40 C | 81.6 kg | Poly-Vinyl Chloride (PVC) | 125 µm | 0.977 in | 24.82 mm | Multimode | OFNR | Multiple Fibers | 96 Fibers Rip Cord | Black | 50 µm |
