337-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 36POS 0.156
| Part | Material - Insulation | Termination Rows | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Contact Finish | Flange Feature | Gender | Read Out | Number of Positions | Mounting Type | Color | Contact Type | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Card Type | Contact Material | Termination | Features | Termination Rows [custom] | Number of Positions/Bay/Row [custom] | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 36 | Gold | Flush Mount M3 Threaded Insert Top Opening | Female | Single | 36 | Through Hole | Green | Cantilever | 1 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Single Edge | Copper Alloy | Solder | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 36 | Gold | 4-40 Threaded Insert Top Mount Opening | Female | Single | 36 | Through Hole | Green | Cantilever | 1 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Single Edge | Copper Alloy | Solder Eyelet(s) | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 4-40 Threaded Insert Top Mount Opening | Female | Dual | 36 | Right Angle Through Hole | Green | Cantilever | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Copper Alloy | Wire Wrap | Card Guides | 2 | 18 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 4-40 Threaded Insert Top Mount Opening | Female | Dual | 36 | Through Hole | Green | Cantilever | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Copper Alloy | Wire Wrap | 2 | 18 | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Dual | 36 | Right Angle Through Hole | Green | Cantilever | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Copper Alloy | Wire Wrap | 2 | 18 | 2 | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 4-40 Threaded Insert Top Mount Opening | Female | Dual | 36 | Through Hole | Green | Cantilever | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Copper Alloy | Wire Wrap | 2 | 18 | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 4-40 Threaded Insert Top Mount Opening | Female | Dual | 36 | Right Angle Through Hole | Green | Cantilever | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Copper Alloy | Wire Wrap | Card Guides | 2 | 18 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 36 | Gold | Floating Bobbin Top Mount Opening | Female | Single | 36 | Through Hole | Green | Cantilever | 1 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Single Edge | Copper Alloy | Wire Wrap | 0.116 " | 2.95 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Floating Bobbin Top Mount Opening | Female | Dual | 36 | Through Hole | Green | Cantilever | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Copper Alloy | Solder Eyelet(s) | 2 | 18 | 2 | 0.116 " | 2.95 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Female | Dual | 36 | Through Hole | Green | Cantilever | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Copper Alloy | Solder | Card Guides | 2 | 18 | 2 |
