8530 Series

Catalog

HOOK-UP SOLID 22AWG BLACK 100'

Part	Cable Type	Jacket (Insulation) Material	Wire Gauge	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Operating Temperature	Qualification	Features	Voltage	Conductor Material	Length [x]	Length [x]	Jacket Color	Conductor Strand	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length	Length
Belden Inc. 8530 010100	Hook-Up	Poly-Vinyl Chloride (PVC)	22 AWG	0.43 mm	0.017 "	80 °C	MIL-W-76C Type MW	Chemical Resistant	1 kV	Copper Tinned	100 ft	30.5 m	Black	Solid	1.5 mm	0.059 "
Belden Inc. 8530 0091000	Hook-Up	Poly-Vinyl Chloride (PVC)	22 AWG	0.43 mm	0.017 "		MIL-W-76C Type MW	Chemical Resistant	1 kV	Copper Tinned			White	Solid	1.5 mm	0.059 "	304.8 m	1000 ft
Belden Inc. 8530 0101000	Hook-Up	Poly-Vinyl Chloride (PVC)	22 AWG	0.43 mm	0.017 "		MIL-W-76C Type MW	Chemical Resistant	1 kV	Copper Tinned			Black	Solid	1.5 mm	0.059 "	304.8 m	1000 ft
Belden Inc. 8530 005100	Hook-Up	Poly-Vinyl Chloride (PVC)	22 AWG	0.43 mm	0.017 "		MIL-W-76C Type MW	Chemical Resistant	1 kV	Copper Tinned	100 ft	30.5 m	Green	Solid	1.5 mm	0.059 "
Belden Inc. 8530 009100	Hook-Up	Poly-Vinyl Chloride (PVC)	22 AWG	0.43 mm	0.017 "	80 °C	MIL-W-76C Type MW	Chemical Resistant	1 kV	Copper Tinned	100 ft	30.5 m	White	Solid	1.5 mm	0.059 "
Belden Inc. 8530 0031000	Hook-Up	Poly-Vinyl Chloride (PVC)	22 AWG	0.43 mm	0.017 "		MIL-W-76C Type MW	Chemical Resistant	1 kV	Copper Tinned			Orange	Solid	1.5 mm	0.059 "	304.8 m	1000 ft
Belden Inc. 8530 0041000	Hook-Up	Poly-Vinyl Chloride (PVC)	22 AWG	0.43 mm	0.017 "		MIL-W-76C Type MW	Chemical Resistant	1 kV	Copper Tinned			Yellow	Solid	1.5 mm	0.059 "	304.8 m	1000 ft
Belden Inc. 8530 0061000	Hook-Up	Poly-Vinyl Chloride (PVC)	22 AWG	0.43 mm	0.017 "		MIL-W-76C Type MW	Chemical Resistant	1 kV	Copper Tinned			Blue	Solid	1.5 mm	0.059 "	304.8 m	1000 ft
Belden Inc. 8530 003100	Hook-Up	Poly-Vinyl Chloride (PVC)	22 AWG	0.43 mm	0.017 "		MIL-W-76C Type MW	Chemical Resistant	1 kV	Copper Tinned	100 ft	30.5 m	Orange	Solid	1.5 mm	0.059 "
