3SB2206 Series

Manufacturer: Siemens

Catalog

PUSHBUTTON,MOMENTARY,EXT,CLR,ILL

Part	Mechanical Life	Voltage Rating - DC	Type	Circuit	Color - Actuator/Cap	Actuator Type	Current Rating (Amps)	Switch Function	Termination Style	Panel Cutout Dimensions [diameter]	Ingress Protection	Voltage Rating - AC	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type
Siemens 3SB22060LH01	3000000 Cycles	24 V	Illuminated Standard	SPST-NO	Clear	Button Round	6 A 10 A	Off-Mom	Quick Connect	16 mm	IP65 - Dust Tight Water Resistant	110 V	-25 °C	60 °C	Panel Mount Front
Siemens 3SB22060AF01	3000000 Cycles	24 V	Illuminated Standard	SPST-NO	Blue	Button Flush Round	6 A 10 A	Off-Mom	Quick Connect	16 mm	IP65 - Dust Tight Water Resistant	110 V	-25 °C	60 °C	Panel Mount Front
Siemens 3SB22060LD01	3000000 Cycles	24 V	Illuminated Standard	SPST-NO	Yellow	Button Round	6 A 10 A	Off-Mom	Quick Connect	16 mm	IP65 - Dust Tight Water Resistant	110 V	-25 °C	60 °C	Panel Mount Front
Siemens 3SB22060AD01	3000000 Cycles	24 V	Illuminated Standard	SPST-NO	Yellow	Button Flush Round	6 A 10 A	Off-Mom	Quick Connect	16 mm	IP65 - Dust Tight Water Resistant	110 V	-25 °C	60 °C	Panel Mount Front
Siemens 3SB22060LE01	3000000 Cycles	24 V	Illuminated Standard	SPST-NO	Green	Button Round	6 A 10 A	Off-Mom	Quick Connect	16 mm	IP65 - Dust Tight Water Resistant	110 V	-25 °C	60 °C	Panel Mount Front
Siemens 3SB22060AH01	3000000 Cycles	24 V	Illuminated Standard	SPST-NO	Clear	Button Flush Round	6 A 10 A	Off-Mom	Quick Connect	16 mm	IP65 - Dust Tight Water Resistant	110 V	-25 °C	60 °C	Panel Mount Front
Siemens 3SB22060AE01	3000000 Cycles	24 V	Illuminated Standard	SPST-NO	Green	Button Flush Round	6 A 10 A	Off-Mom	Quick Connect	16 mm	IP65 - Dust Tight Water Resistant	110 V	-25 °C	60 °C	Panel Mount Front
Siemens 3SB22060LF01	3000000 Cycles	24 V	Illuminated Standard	SPST-NO	Blue	Button Round	6 A 10 A	Off-Mom	Quick Connect	16 mm	IP65 - Dust Tight Water Resistant	110 V	-25 °C	60 °C	Panel Mount Front
