MU425S48 Series
Manufacturer: SL POWER / Advanced Energy
Beta
⌘K
AC/DC CONVERTER 48V 300W
| Part | Minimum Load Required | Applications | Number of Outputs | Current - Output 1 | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Voltage - Isolation | Type | Features | Voltage - Output 1 | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Efficiency | Voltage - Input [Max] | Voltage - Input [Min] | Power (Watts) | Power (Watts) | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SL POWER / Advanced Energy | ITE (Commercial) | 1 | 5.9 A | 70 °C | -10 °C | Chassis Mount | 1.5 kV | Open Frame | Adjustable Output PFC Remote On/Off Remote Sense Standby Output Universal Input | 48 V | 83.8 mm | 6.2 in | 1.62 " | 41.1 mm | 3.3 " | 157.4 mm | 90 % | 264 VAC | 90 VAC | 300 W | 425 W | CE | ||
 SL POWER / Advanced Energy | Medical | 1 | 5.9 A | 70 °C | -10 °C | Chassis Mount | 1.5 kV | Enclosed | Adjustable Output PFC Remote Sense Standby Output Universal Input | 48 V | 83.8 mm | 6.2 in | 1.62 " | 41.1 mm | 3.3 " | 157.5 mm | 88 % | 264 VAC 300 V | 90 VAC 120 VDC | 283 W 403 W | CE | 60601-1 |
