745-027 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 27POS 0.100
| Part | Termination Rows | Material - Insulation | Termination | Contact Finish | Pitch | Pitch | Number of Positions | Contact Type | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Number of Positions/Bay/Row | Card Type | Read Out | Contact Material | Color | Gender | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Press-Fit | Gold | 0.1 " | 2.54 mm | 27 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Through Hole | 27 | Non Specified - Single Edge | Single | Copper Alloy | Black | Female | 30 Áin | 0.76 Ám |
 EDAC Inc. | 1 | Polyester Thermoplastic | Press-Fit Wire Wrap | Gold | 0.1 " | 2.54 mm | 27 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Through Hole | 27 | Non Specified - Single Edge | Single | Copper Alloy | Black | Female | 30 Áin | 0.76 Ám |
 EDAC Inc. | 1 | Polyester Thermoplastic | Press-Fit | Gold | 0.1 " | 2.54 mm | 27 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Through Hole | 27 | Non Specified - Single Edge | Single | Copper Alloy | Black | Female | 30 Áin | 0.76 Ám |
 EDAC Inc. | 1 | Polyester Thermoplastic | Press-Fit Wire Wrap | Gold | 0.1 " | 2.54 mm | 27 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Through Hole | 27 | Non Specified - Single Edge | Single | Copper Alloy | Black | Female | 30 Áin | 0.76 Ám |
 EDAC Inc. | 1 | Polyester Thermoplastic | Press-Fit Wire Wrap | Gold | 0.1 " | 2.54 mm | 27 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Through Hole | 27 | Non Specified - Single Edge | Single | Copper Alloy | Black | Female | 30 Áin | 0.76 Ám |
 EDAC Inc. | 1 | Polyester Thermoplastic | Press-Fit | Gold | 0.1 " | 2.54 mm | 27 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Through Hole | 27 | Non Specified - Single Edge | Single | Copper Alloy | Black | Female | 30 Áin | 0.76 Ám |
 EDAC Inc. | 1 | Polyester Thermoplastic | Press-Fit | Gold | 0.1 " | 2.54 mm | 27 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Through Hole | 27 | Non Specified - Single Edge | Single | Copper Alloy | Black | Female | 30 Áin | 0.76 Ám |
 EDAC Inc. | 1 | Polyester Thermoplastic | Press-Fit | Gold | 0.1 " | 2.54 mm | 27 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Through Hole | 27 | Non Specified - Single Edge | Single | Copper Alloy | Black | Female | 30 Áin | 0.76 Ám |
