3412 Series
Manufacturer: ebm-papst Inc.
Beta
⌘K
FAN AXIAL 92X25.4MM 12VDC WIRE
| Part | Voltage Range [Max] | Voltage Range [Min] | Lifetime @ Temp. | Material - Frame | Air Flow | Air Flow | Material - Blade | Termination | Bearing Type | Noise | RPM | Size / Dimension [y] | Size / Dimension [x] | Voltage - Rated | Weight | Weight | Width [y] | Fan Type | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | 15 V | 8 V | 70000 Hrs | Fiberglass Reinforced Polybutylene Terephthalate (PBT) | 55.3 CFM | 1.55 m³/min | Polyamide (PA) Nylon Fiberglass Reinforced | 2 Wire Leads | Ball | 36 dB | 3000 RPM | 92 mm | 92 mm | 12 VDC | 99.79 g | 0.22 lb | 25.4 mm | Tubeaxial | CSA UL VDE | -20 ░C | 70 °C |
