337-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 7POS 0.156
| Part | Termination Rows | Material - Insulation | Gender | Color | Termination | Pitch | Pitch | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Flange Feature | Mounting Type | Read Out | Number of Positions/Bay/Row | Number of Rows | Number of Positions | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Solder | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Wire Wrap | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Wire Wrap | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Wire Wrap | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 4-40 Threaded Insert Top Mount Opening | Right Angle Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Wire Wrap | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Flush Mount Top Opening Unthreaded | Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Solder | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Wire Wrap | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Flush Mount Top Opening Unthreaded | Right Angle Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Solder | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Wire Wrap | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Right Angle Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Green | Wire Wrap | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 4-40 Threaded Insert Top Mount Opening | Right Angle Through Hole | Single | 7 | 1 | 7 | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Card Guides |
