Blowers & Centrifugal Fans AC Centrifugal Blower
Blowers & Centrifugal Fans AC Centrifugal Blower
| Part | Current Rating (Amps) | Material - Frame | Material - Blade | Ingress Protection | Features | Bearing Type | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Rated | Width [y] | Power (Watts) | Fan Type | Approval Agency | RPM | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension | Termination | Weight [custom] | Weight [custom] | Size / Dimension [z] | Weight [custom] | Weight [custom] | Air Flow | Air Flow | Noise | Operating Temperature | Size / Dimension [diameter] | Weight | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | 0.26 A | Steel | Steel | IP22 | Capacitor Thermal Overload Protector (TOP) | Ball | 50 °C | -25 °C | -25 °C | 50 °C | 230 VAC | 146 mm | 54 W | Blower Centrifugal | CCC CE EAC | 1200 RPM | 165 mm | 161 mm | Rectangular/Rounded | 3 Wire Leads | ||||||||||||
 ebm-papst Inc. | Steel | Steel | IP20 | Ball | 230 VAC | 180 mm | Blower Centrifugal | CCC CE GOST | 162 mm | Rectangular/Rounded | 2 Wire Leads | 3.2 lbs | 1.5 kg | 165 mm | ||||||||||||||||||
 ebm-papst Inc. | 0.45 A | Steel | Steel | IP20 | Capacitor Thermal Overload Protection (TOP) | Ball | 230 VAC | 180 mm | 100 W | Blower Centrifugal | CCC CE GOST | 1850 RPM | 162 mm | Rectangular/Rounded | 2 Wire Leads | 165 mm | 3.3 lbs | 1.5 kg | 6.76 m³/min | 241.3 CFM | 57 dB | 35 °C | ||||||||||
 ebm-papst Inc. | 0.34 A | Steel | Steel | IP20 | Capacitor Thermal Overload Protector (TOP) | Ball | -25 °C | 30 °C | 230 VAC | 146 mm | 77 W | Blower Centrifugal | CE | 1750 RPM | 165 mm | 161 mm | Rectangular/Rounded | 4 Wire Leads | ||||||||||||||
 ebm-papst Inc. | Steel | Steel | Ball | 230 VAC | 140 mm | 42 W | Blower Centrifugal | 137 mm | 144 mm | 2 Wire Leads | 2.9 lbs | 1.3 kg | 2.97 m³/min | 106 CFM | 47 dB | 97 mm | ||||||||||||||||
 ebm-papst Inc. | IP20 | Capacitor Thermal Overload Protector (TOP) | Ball | -25 °C | 35 °C | 230 VAC | 180 mm | 100 W | Blower Centrifugal | CCC CE EAC | 1850 RPM | 162 mm | Rectangular/Rounded | 4 Wire Leads | 165 mm | |||||||||||||||||
 ebm-papst Inc. | 0.26 A | Steel | Steel | IP20 | Capacitor Thermal Overload Protector (TOP) | Ball | 90 °C | -25 °C | -25 °C | 90 °C | 230 VAC | 146 mm | 58 W | Blower Centrifugal | CE EAC | 2700 RPM | 165 mm | 161 mm | Rectangular/Rounded | 3 Wire Leads with QC Receptacles | ||||||||||||
ebm-papst Inc. | Steel | Steel | Ball | 230 VAC | 140 mm | 42 W | Blower Centrifugal | 137 mm | 144 mm | 2 Wire Leads | 2.9 lbs | 1.3 kg | 2.97 m³/min | 106 CFM | 47 dB | 97 mm | ||||||||||||||||
 ebm-papst Inc. | 0.45 A | Steel | Steel | IP20 | Ball | -40 C | 80 °C | 230 VAC | 146 mm | 100 W | Blower Centrifugal | CE | 1850 RPM | 165 mm | 161 mm | Rectangular | 3 Wire Leads | 3.3 lbs | 1.5 kg | 97 mm | ||||||||||||
ebm-papst Inc. | Steel | Steel | Ball | 115 VAC | 140 mm | 43 W | Blower Centrifugal | CCC CE CSA UL | 137 mm | 144 mm | 2 Wire Leads | 3.36 m³/min | 120 CFM | 47 dB | 97 mm | 2.7 lbs | 1.2 kg |
