396-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 22POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Material | Card Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Contact Type | Color | Number of Positions | Gender | Contact Finish | Read Out | Pitch | Pitch | Flange Feature | Mounting Type | Termination Rows [custom] | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 22 | 0.25 Ám | 10 Áin | 1 | -40 C | 105 ░C | Wire Wrap | Cantilever | Black | 22 | Female | Gold | Single | 3.18 mm | 0.125 in | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 22 | 0.25 Ám | 10 Áin | 1 | -40 C | 105 ░C | Solder | Cantilever | Black | 22 | Female | Gold | Single | 3.18 mm | 0.125 in | M3 Threaded Insert Top Mount Opening | Through Hole | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 11 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Solder | Cantilever | Black | 22 | Female | Gold | Dual | 3.18 mm | 0.125 in | Floating Bobbin Top Mount Opening | Through Hole | 2 | 2 | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 11 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Solder Eyelet(s) | Cantilever | Black | 22 | Female | Gold | Dual | 3.18 mm | 0.125 in | Side Mount Opening Unthreaded | Board Edge Straddle Mount | 2 | 2 | 0.128 " | 3.25 mm | Card Extender | ||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 11 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Wire Wrap | Cantilever | Black | 22 | Female | Gold | Dual | 3.18 mm | 0.125 in | Through Hole | 2 | 2 | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 22 | 0.25 Ám | 10 Áin | 1 | -40 C | 105 ░C | Solder | Cantilever | Black | 22 | Female | Gold | Single | 3.18 mm | 0.125 in | Through Hole | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 11 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Wire Wrap | Cantilever | Black | 22 | Female | Gold | Dual | 3.18 mm | 0.125 in | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 2 | 2 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 22 | 0.25 Ám | 10 Áin | 1 | -40 C | 105 ░C | Solder | Cantilever | Black | 22 | Female | Gold | Single | 3.18 mm | 0.125 in | Flush Mount M3 Threaded Insert Top Opening | Through Hole | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 11 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Wire Wrap | Cantilever | Black | 22 | Female | Gold | Dual | 3.18 mm | 0.125 in | M3 Threaded Insert Top Mount Opening | Through Hole | 2 | 2 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 22 | 0.25 Ám | 10 Áin | 1 | -40 C | 105 ░C | Solder | Cantilever | Black | 22 | Female | Gold | Single | 3.18 mm | 0.125 in | 4-40 Threaded Insert Top Mount Opening | Through Hole |
