60-12-8302 Series

Catalog

THERM PAD 18.03MMX12.7MM W/ADH

Part	Shelf Life Start	Shelf Life	Thermal Conductivity	Thickness	Thickness	Shape	Outline [y]	Outline [x]	Usage	Backing, Carrier [custom]	Backing, Carrier [custom]	Color	Material	Adhesive	Type	Thickness
Parker Chomerics 60-12-8302-1671	Date of Shipment	18 Months	2.6 W/m-K	0.015 "	0.381 mm	Rectangular	12.7 mm	18.03 mm	TO-220	Fiberglass	Fiberglass	White	Silicone	Adhesive - One Side	Insulator Pad Sheet
Parker Chomerics 60-12-8302-1674	Date of Shipment	12 Months			10 mils	Rectangular	12.7 mm	18.03 mm	TO-220	Fiberglass	Fiberglass	Blue		Adhesive - One Side	Insulator Pad Sheet	0.01 in
Parker Chomerics 60-12-8302-T441-08	Date of Shipment	18 Months	1.1 W/m-K	0.008 in	0.203 mm	Rectangular	12.7 mm	18.03 mm	TO-220	Fiberglass	Fiberglass	Pink		Adhesive - One Side	Insulator Pad Sheet
Parker Chomerics 60-12-8302-T500	Date of Shipment	18 Months	2.1 W/m-K		10 mils	Rectangular	12.7 mm	18.03 mm	TO-220	Fiberglass	Fiberglass	Green		Adhesive - One Side	Insulator Pad Sheet	0.01 in
