MPXV2 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
SENSOR 29.01PSIG 0.13" .04V
| Part | Output Voltage (Min) | Output Voltage (Max) | Package / Case | Port Diameter | Port Gender | Port Feature | Pressure Type | Operating Pressure | Operating Temperature (Max) | Operating Temperature (Min) | Maximum Pressure | Features | Port Style | Applications | Termination Style | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Output Type | Mounting Type | Package Name | Accuracy Range Maximum | Accuracy Range Minimum | Package Features | Package Length | Package Width |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | 0 mV | 40 mV | 8-SMD Gull Wing Top Port | 0.13 " | Male | Tube | Vented Gauge | 29.01 PSI | 125 °C | -40 °C | 58.02 PSI | Temperature Compensated | Barbless | Board Mount | Gull Wing | 16 V | 10 VDC | Wheatstone Bridge | Surface Mount | ||||||
 NXP USA Inc. | 0 mV | 40 mV | 8-SMD Module | 0.13 " | Male | Tube | Vented Gauge | 7.25 PSI | 125 °C | -40 °C | 29.01 PSI | Temperature Compensated | Barbed | Board Mount | SMD (SMT) Tab | 16 V | 10 VDC | Wheatstone Bridge | Surface Mount | 8-SOP | 0.4 % | -0.6 % | |||
 NXP USA Inc. | 0 V | 40 mV | 8-SMD Gull Wing Top Port | 0.19 " | Male | Dual Tube | Absolute Differential Gauge | 29.01 PSI | 125 °C | -40 °C | 58.02 PSI | Temperature Compensated | Barbed | Board Mount | 16 V | 10 VDC | Wheatstone Bridge | Surface Mount | |||||||
 NXP USA Inc. | 0 mV | 40 mV | 8-SMD Gull Wing Side Port | 0.13 " | Male | Tube | Vented Gauge | 7.25 PSI | 125 °C | -40 °C | 29.01 PSI | Temperature Compensated | Barbed | Board Mount | Gull Wing | 16 V | 10 VDC | Wheatstone Bridge | Surface Mount | 8-SOP | 0.4 % | -0.6 % | |||
NXP USA Inc. | 0 mV | 40 mV | 8-SMD Gull Wing Top Port | 0.13 " | Male | Tube | Vented Gauge | 29.01 PSI | 125 °C | -40 °C | 58.02 PSI | Temperature Compensated | Barbless | Board Mount | Gull Wing | 16 V | 10 VDC | Wheatstone Bridge | Surface Mount | ||||||
NXP USA Inc. | 0 mV | 40 mV | 8-SMD Gull Wing Top Port | 0.13 " | Male | Tube | Vented Gauge | 29.01 PSI | 125 °C | -40 °C | 58.02 PSI | Temperature Compensated | Barbless | Board Mount | Gull Wing | 16 V | 10 VDC | Wheatstone Bridge | Surface Mount | ||||||
 NXP USA Inc. | 0 mV | 40 mV | 0.13 " | Male | Tube | Differential | 29.01 PSI | 125 °C | -40 °C | 58.02 PSI | Temperature Compensated | Barbed | Board Mount | Gull Wing | 16 V | 10 VDC | Wheatstone Bridge | Surface Mount | 8-BSOP 8-SOP | Dual Ports Same Side | 0.475 \ | 12.06 mm | |||
NXP USA Inc. | 0 mV | 40 mV | 8-SMD Gull Wing Side Port | 0.13 " | Male | Tube | Vented Gauge | 29.01 PSI | 125 °C | -40 °C | 58.02 PSI | Temperature Compensated | Barbed | Board Mount | Gull Wing | 16 V | 10 VDC | Wheatstone Bridge | Surface Mount | 8-SOP |
