F221V1/16 Series

Catalog

FIT221V1/16 WHITE 25X4 FT ROHS COMPLIANT: YES

Part	Shelf Life Start	Type	Color	Shrink Temperature	Shelf Life	Material	Length [x]	Length [x]	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Features	Recovered Wall Thickness	Recovered Wall Thickness	Shrinkage Ratio [Min]	Shrinkage Ratio [Max]	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Operating Temperature [Min]	Operating Temperature [Max]	Length	Length
ALPHA WIRE F221V1/16 WH103	Date of Manufacture	Tubing Flexible	White	90 °C	144 Months	Polyolefin (PO) Irradiated	4 ft	1.22 m	0.062 in	1.57 mm	Flame Retardant Fluid Resistant Heat Resistant	0.43 mm	0.017 in	1	2	0.031 in	0.79 mm	-55 C	135 °C
ALPHA WIRE F221V1/16 RD001	Date of Manufacture	Tubing Flexible	Red	90 °C	144 Months	Polyolefin (PO) Irradiated			0.062 in	1.57 mm	Flame Retardant Fluid Resistant Heat Resistant	0.43 mm	0.017 in	1	2	0.031 in	0.79 mm	-55 C	135 °C	304.8 m	1000 ft
ALPHA WIRE F221V1/16 BK205	Date of Manufacture	Tubing Flexible	Black	90 °C	144 Months	Polyolefin (PO) Irradiated			0.062 in	1.57 mm	Flame Retardant Fluid Resistant Heat Resistant UV Resistant	0.43 mm	0.017 in	1	2	0.031 in	0.79 mm	-55 C	135 °C	304.8 m	1000 ft
