282959 Series

Catalog

TERMI-BLOK PLUG 5P. 7

Part	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Positions Per Level	Material Flammability Rating	Screw Size	Voltage - UL	Type	Wire Strip Length [Max]	Wire Strip Length [Min]	Pitch [x]	Pitch [x]	Torque - Screw	Torque - Screw	Color	Number of Levels	Insulation Height	Insulation Height	Contact Mating Finish	Contact Material	Termination Style	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]	Mounting Type	Number of Positions	Wire Gauge or Range - mm˛ [Max]	Wire Gauge or Range - mm˛ [Min]
TE Connectivity Raychem Cable Protection 282959-5	30 AWG	12 AWG	-40 °C	110 °C	5	UL94 V-0	M3	300 V	Plug Female Sockets	7.5 mm	6 mm	0.295 in	7.5 mm	0.79 Nm	7 Lb-In	Green	1	0.61 in	15.49 mm	Tin	Phosphor Bronze	Screw - Rising Cage Clamp	0.05 mm²	2 mm²	Free Hanging (In-Line)
TE Connectivity Raychem Cable Protection 282959-3	30 AWG	12 AWG	-40 °C	110 °C	3	UL94 V-0	M3	300 V	Plug Female Sockets	7.5 mm	6 mm	0.295 in	7.5 mm	0.79 Nm	7 Lb-In	Green	1	0.61 in	15.49 mm	Tin	Phosphor Bronze	Screw - Rising Cage Clamp	0.05 mm²	2 mm²	Free Hanging (In-Line)
TE Connectivity Raychem Cable Protection 282959-2	30 AWG	12 AWG	-40 °C	110 °C	2	UL94 V-0	M3	300 V	Plug Female Sockets	7.5 mm	6 mm	0.295 in	7.5 mm	0.79 Nm	7 Lb-In	Green	1	0.61 in	15.49 mm	Tin	Phosphor Bronze	Screw - Rising Cage Clamp			Free Hanging (In-Line)	2	2 mm˛	0.05 mm˛
