ECW-F2105 Series

Manufacturer: Panasonic Electronic Components

Catalog

CAP FILM 1UF 5% 250VDC RADIAL

Part	Applications	Voltage Rating - DC	Package / Case	Tolerance	Operating Temperature [Min]	Operating Temperature [Max]	Dielectric Material	Lead Spacing	Lead Spacing	Mounting Type	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Capacitance	Termination	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Voltage Rating - AC	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [y]	Lead Spacing [x]	Lead Spacing [x]
Panasonic Electronic Components ECW-F2105JAQ	High Frequency Switching	250 V	Radial	5 %	-40 C	105 ░C	Polypropylene (PP) Metallized	15 mm	0.591 in	Through Hole	18.1 mm	0.713 "	0.335 in	8.5 mm	1 µF	PC Pins	21.8 mm	0.858 "
Panasonic Electronic Components ECW-F2105JA	High Frequency Switching	250 V	Radial	5 %	-40 C	105 ░C	Polypropylene (PP) Metallized	15 mm	0.591 in	Through Hole	18.1 mm	0.713 "	0.335 in	8.5 mm	1 µF	PC Pins		14.8 mm	125 V	0.583 in
Panasonic Electronic Components ECW-F2105JAB	High Frequency Switching	250 V	Radial	5 %	-40 C	105 ░C	Polypropylene (PP) Metallized	7.5 mm	0.295 in	Through Hole	18.1 mm	0.713 "	0.335 in	8.5 mm	1 µF	PC Pins					0.78 in	19.8 mm
Panasonic Electronic Components ECW-F2105JB	High Frequency Switching	250 V	Radial	5 %	-25 °C	85 °C	Polypropylene (PP) Metallized			Through Hole	23 mm	0.906 in	0.453 in		1 µF	PC Pins		19.5 mm		0.768 in			11.5 mm	0.787 in	20 mm
Panasonic Electronic Components ECW-F2105HAB	High Frequency Switching	250 V	Radial	3 %	-40 C	105 ░C	Polypropylene (PP) Metallized	7.5 mm	0.295 in	Through Hole	18.1 mm	0.713 "	0.335 in	8.5 mm	1 µF	PC Pins					0.78 in	19.8 mm
Panasonic Electronic Components ECW-F2105HA	High Frequency Switching	250 V	Radial	3 %	-40 C	105 ░C	Polypropylene (PP) Metallized	15 mm	0.591 in	Through Hole	18.1 mm	0.713 "	0.335 in	8.5 mm	1 µF	PC Pins		14.8 mm		0.583 in
