J01440A3 Series
Manufacturer: Telegartner Inc
Beta
⌘K
4.3-10 PLG 90 SD/CR PP G30
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Center Contact Plating | Dielectric Material | Body Finish | Body Material | Center Contact Material | Fastening Type | Ingress Protection | Number of Ports | Contact Termination | Frequency - Max [Max] | Impedance | Connector Type | Connector Style | Housing Color | Mounting Type | Shield Termination | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Telegartner Inc | 85 °C | -40 C | Silver | Polytetrafluoroethylene (PTFE) | White Bronze | Brass | Brass | Threaded | IP67 - Dust Tight Waterproof | 1 | Solder | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) Right Angle | Crimp | |
 Telegartner Inc | 85 °C | -40 C | Silver | Polytetrafluoroethylene (PTFE) | White Bronze | Brass | Brass | Threaded | 1 | Crimp | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) | Crimp | ||
 Telegartner Inc | 155 C | -55 C | Silver | Polytetrafluoroethylene (PTFE) | Silver | Brass | Brass | Threaded | IP67 - Dust Tight Waterproof | 1 | Solder | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) | Solder | |
 Telegartner Inc | 85 °C | -40 C | Silver | Polytetrafluoroethylene (PTFE) | Silver | Beryllium Copper | Copper Alloy | Threaded | IP68 - Dust Tight Waterproof | 1 | Crimp Solder | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) | Clamp | 1100 V |
 Telegartner Inc | 85 °C | -40 C | Silver | Polytetrafluoroethylene (PTFE) | White Bronze | Brass | Copper Alloy | Threaded | IP68 - Dust Tight Waterproof | 1 | Crimp Solder | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) Right Angle | Clamp | 1000 VDC |
 Telegartner Inc | 85 °C | -40 C | Silver | Polytetrafluoroethylene (PTFE) | White Bronze | Brass | Copper Alloy | Threaded | IP67 - Dust Tight Waterproof | 1 | Crimp Solder | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) | Clamp | 1500 V |
 Telegartner Inc | 85 °C | -40 C | Silver | Polytetrafluoroethylene (PTFE) | White Bronze | Brass | Copper Alloy | Threaded | 1 | Crimp | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) | Crimp | ||
 Telegartner Inc | 155 C | -55 C | Silver | Polytetrafluoroethylene (PTFE) | Silver | Brass | Brass | Threaded | IP67 - Dust Tight Waterproof | 1 | Solder | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) | Solder | |
 Telegartner Inc | 100 °C | -30 ░C | Silver | Polytetrafluoroethylene (PTFE) | White Bronze | Brass | Copper Alloy | Threaded | IP67 - Dust Tight Waterproof | 1 | Crimp Solder | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) | Clamp | 1800 V |
 Telegartner Inc | 85 °C | -40 C | Silver | Polytetrafluoroethylene (PTFE) | White Bronze | Brass | Copper Alloy | Threaded | IP68 - Dust Tight Waterproof | 1 | Crimp Solder | 6000 MHz | 50 Ohms | Plug Male Pin | 4.3/10 | Silver | Free Hanging (In-Line) Right Angle | Clamp | 1000 VDC |
