892-070 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 70POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Flange Feature | Pitch | Pitch | Contact Material | Mounting Type | Card Type | Color | Number of Positions/Bay/Row | Contact Type | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Termination | Read Out | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Dual | 2 | 0.25 Ám | 10 Áin | Gold | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | Copper Alloy | Board Edge Straddle Mount | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Dual | 2 | 0.25 Ám | 10 Áin | Gold | Card Extender | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | Flush Mount Side Opening Unthreaded | 0.1 " | 2.54 mm | Copper Alloy | Right Angle Through Hole | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Dual | 2 | 0.25 Ám | 10 Áin | Gold | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | 0.1 " | 2.54 mm | Copper Alloy | Board Edge Straddle Mount | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Dual | 2 | 0.25 Ám | 10 Áin | Gold | Card Extender | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | Floating Bobbin Flush Mount | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Dual | 2 | 0.25 Ám | 10 Áin | Gold | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | Flush Mount Top Opening Unthreaded | 0.1 " | 2.54 mm | Copper Alloy | Board Edge Straddle Mount | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Dual | 2 | 0.25 Ám | 10 Áin | Gold | Card Extender | 0.128 " | 3.25 mm |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | Floating Bobbin Flush Mount | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Dual | 2 | 0.25 Ám | 10 Áin | Gold | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | Copper Alloy | Board Edge Straddle Mount | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Dual | 2 | 0.25 Ám | 10 Áin | Gold | Card Extender | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | Flush Mount Top Opening Unthreaded | 0.1 " | 2.54 mm | Copper Alloy | Right Angle Through Hole | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Dual | 2 | 0.25 Ám | 10 Áin | Gold | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Female | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Non Specified - Dual Edge | Black | 35 | Cantilever | 70 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Dual | 2 | 0.25 Ám | 10 Áin | Gold |
