146134 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

CONN HEADER SMD 24POS 2.54MM

Part	Voltage Rating	Fastening Type	Insulation Height	Insulation Height	Insulation Material	Operating Temperature [Max]	Operating Temperature [Min]	Contact Shape	Insulation Color	Pitch - Mating	Pitch - Mating	Current Rating (Amps)	Number of Rows	Contact Length - Mating [x]	Contact Length - Mating	Style	Contact Finish - Post	Number of Positions Loaded	Contact Type	Number of Positions	Mounting Type	Termination	Material Flammability Rating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Shrouding	Connector Type	Contact Finish - Mating	Number of Positions
TE Connectivity Raychem Cable Protection 6-146134-1	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin	All	Male Pin	24	Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header
TE Connectivity Raychem Cable Protection 146134-2	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin-Lead	All	Male Pin	6	Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header	Tin-Lead
TE Connectivity Raychem Cable Protection 6-146134-0	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin	All	Male Pin	22 positions	Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header
TE Connectivity Raychem Cable Protection 6-146134-3	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin	All	Male Pin	28	Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header
TE Connectivity Raychem Cable Protection 1-146134-2	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin-Lead	All	Male Pin	26	Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header	Tin-Lead
TE Connectivity Raychem Cable Protection 146134-3	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin-Lead	All	Male Pin	8	Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header	Tin-Lead
TE Connectivity Raychem Cable Protection 1-146134-6	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin	All	Male Pin	6	Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header
TE Connectivity Raychem Cable Protection 1-146134-4	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin-Lead	All	Male Pin	30	Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header	Tin-Lead
TE Connectivity Raychem Cable Protection 5-146134-5	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin	All	Male Pin	12	Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header
TE Connectivity Raychem Cable Protection 1-146134-9	30 VAC	Push-Pull	0.09 in	2.29 mm	Liquid Crystal Polymer (LCP)	125 °C	-65 ░C	Square	Black	0.1 in	2.54 mm	3 A	2	0.23 in	5.84 mm	Board to Board Cable	Tin	All	Male Pin		Surface Mount	Solder	UL94 V-0	2.54 µm	100 µin	2.54 mm	0.1 in	2.54 çm	100 çin	Copper Alloy	Unshrouded	Breakaway Header		16
