10GX62F Series

Catalog

CAT6A 4PRB F/UTP CMR REEL

Part	Shield Material	Shield Coverage	Wire Gauge	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Conductor Material	Conductor Insulation	Conductor Insulation	Number of Conductors	Cable Type	Features	Length	Length	Jacket (Insulation) Material	Usage	Shield Type	Voltage	Ratings	Conductor Strand
Belden Inc. 10GX62F 0021000	Aluminum Polyester	100 %	23 AWG	7.62 mm	0.3 in	Red	Copper Bare	Polyolefin	PO	8	Multi-Pair Cat6a	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC) Riser	Network	Foil	300 VDC	UL Style CMR	Solid
Belden Inc. 10GX62F 0091000	Aluminum Polyester	100 %	23 AWG	7.62 mm	0.3 in	White	Copper Bare	Polyolefin	PO	8	Multi-Pair Cat6a	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC) Riser	Network	Foil	300 VDC	UL Style CMR	Solid
Belden Inc. 10GX62F 0081000	Aluminum Polyester	100 %	23 AWG	7.62 mm	0.3 in	Gray	Copper Bare	Polyolefin	PO	8	Multi-Pair Cat6a	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC) Riser	Network	Foil	300 VDC	UL Style CMR	Solid
Belden Inc. 10GX62F 0041000	Aluminum Polyester	100 %	23 AWG	7.62 mm	0.3 in	Yellow	Copper Bare	Polyolefin	PO	8	Multi-Pair Cat6a	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC) Riser	Network	Foil	300 VDC	UL Style CMR	Solid
Belden Inc. 10GX62F 0061000	Aluminum Polyester	100 %	23 AWG	7.62 mm	0.3 in	Blue	Copper Bare	Polyolefin	PO	8	Multi-Pair Cat6a	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC) Riser	Network	Foil	300 VDC	UL Style CMR	Solid
Belden Inc. 10GX62F 0101000	Aluminum Polyester	100 %	23 AWG	7.62 mm	0.3 in	Black	Copper Bare	Polyolefin	PO	8	Multi-Pair Cat6a	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC) Riser	Network	Foil	300 VDC	UL Style CMR	Solid
