173-050 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 50POS R/A SLDR
| Part | Color | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Connector Style | Contact Finish Thickness | Contact Type | Features | Material Flammability Rating | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Mounting Type | Current Rating (Amps) | Number of Rows [custom] | Backset Spacing | Backset Spacing | Contact Finish | Flange Feature | Termination | Number of Positions | Connector Type | Shell Material, Finish | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Beige | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | D-Sub | Flash | Signal | Mounting Brackets | UL94 V-0 | Steel | Yellow Chromate Plated | 5 | D DD | Panel Mount Right Angle Through Hole | 5 A | 3 | 7.2 mm | 0.283 in | Gold | 4-40 Mating Side Female Screwlock | Solder | 50 | Plug Male Pins | ||
 NorComp Inc. | White | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | D-Sub | Flash | Signal | Grounding Indents Mounting Brackets | UL94 V-0 | 5 | D DD | Panel Mount Right Angle Through Hole | 5 A | 3 | 7.2 mm | 0.283 in | Gold | 4-40 Mating Side Female Screwlock | Solder | 50 | Plug Male Pins | Nickel Plated Steel | |||
 NorComp Inc. | Beige | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Polyester | D-Sub | Flash | Signal | Mounting Brackets | UL94 V-0 | 5 | D DD | Panel Mount Right Angle Through Hole | 5 A | 3 | 7.2 mm | 0.283 in | Gold | 4-40 Mating Side Female Screwlock | Solder | 50 | Receptacle Female Sockets | Brass |
