395-140 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 140POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row [custom] | Contact Type | Termination | Mounting Type | Card Type | Gender | Read Out | Number of Positions | Color | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Solder | Through Hole | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Wire Wrap | Through Hole | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Solder Eyelet(s) | Board Edge Straddle Mount | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Card Extender Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Solder | Through Hole | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Wire Wrap | Through Hole | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Solder | Through Hole | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Solder | Right Angle Through Hole | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Solder Eyelet(s) | Board Edge Straddle Mount | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.116 " | 2.95 mm | Card Extender |
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Solder | Through Hole | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | 70 | Cantilever | Solder Eyelet(s) | Board Edge Straddle Mount | Non Specified - Dual Edge | Female | Dual | 140 | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.156 " | 3.96 mm | Card Extender |
