90130 Series

Manufacturer: Molex

Catalog

CONN HEADER VERT 40POS 2.54MM

Part	Applications	Contact Length - Mating	Contact Length - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Connector Type	Insulation Height [z]	Insulation Height [z]	Number of Positions Loaded	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Contact Material	Insulation Color	Number of Positions	Contact Length - Post [x]	Contact Length - Post [x]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Fastening Type	Contact Type	Contact Finish - Post	Insulation Material	Style	Shrouding	Mounting Type	Contact Shape	Number of Rows [custom]	Insulation Height	Insulation Height	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Number of Positions [custom]	Contact Finish - Mating
Molex 0901301140	Automotive General Purpose	0.266 in	6.75 mm	118.1 µin	3 µm	Solder	Header	0.429 in	10.9 mm	All	UL94 V-0	0.1 "	2.54 mm	Brass	Black	40	0.114 in	2.9 mm	0.1 in	2.54 mm	Latch Holder	Male Pin	Tin	Polyester Glass Filled	Board to Cable/Wire	Shrouded - 4 Wall	Through Hole	Square	2
Molex 0901303130	Automotive General Purpose	0.266 in	6.75 mm	118.1 µin	3 µm	Solder	Header			All	UL94 V-0	0.1 "	2.54 mm	Brass	Black	30	0.114 in	2.9 mm	0.1 in	2.54 mm	Latch Holder	Male Pin	Tin	Polyester Glass Filled	Board to Cable/Wire	Shrouded - 4 Wall	Right Angle Through Hole	Square	2	0.384 in	9.75 mm
Molex 0901301234	Automotive General Purpose	0.266 in	6.75 mm	15 µin	0.38 µm	Solder	Header	0.429 in	10.9 mm	All	UL94 V-0	0.1 "	2.54 mm	Brass	Black		0.114 in	2.9 mm	0.1 in	2.54 mm	Latch Holder	Male Pin	Tin	Polyester Glass Filled	Board to Cable/Wire	Shrouded - 4 Wall	Through Hole	Square	2			118.1 µin	3 µm	34	Gold
Molex 901303234
Molex 0901303140	Automotive General Purpose	0.266 in	6.75 mm	118.1 µin	3 µm	Solder	Header			All	UL94 V-0	0.1 "	2.54 mm	Brass	Black	40	0.114 in	2.9 mm	0.1 in	2.54 mm	Latch Holder	Male Pin	Tin	Polyester Glass Filled	Board to Cable/Wire	Shrouded - 4 Wall	Right Angle Through Hole	Square	2	0.384 in	9.75 mm
Molex 0901301230	Automotive General Purpose	0.266 in	6.75 mm	15 µin	0.38 µm	Solder	Header	0.429 in	10.9 mm	All	UL94 V-0	0.1 "	2.54 mm	Brass	Black	30	0.114 in	2.9 mm	0.1 in	2.54 mm	Latch Holder	Male Pin	Tin	Polyester Glass Filled	Board to Cable/Wire	Shrouded - 4 Wall	Through Hole	Square	2			118.1 µin	3 µm		Gold
Molex 0901303214	Automotive General Purpose	0.266 in	6.75 mm	15 µin	0.38 µm	Solder	Header			All	UL94 V-0	0.1 "	2.54 mm	Brass	Black	14	0.114 in	2.9 mm	0.1 in	2.54 mm	Latch Holder	Male Pin	Tin	Polyester Glass Filled	Board to Cable/Wire	Shrouded - 4 Wall	Right Angle Through Hole	Square	2	0.384 in	9.75 mm	118.1 µin	3 µm		Gold
Molex 0901301110	Automotive General Purpose	0.266 in	6.75 mm	118.1 µin	3 µm	Solder	Header	0.429 in	10.9 mm	All	UL94 V-0	0.1 "	2.54 mm	Brass	Black	10	0.114 in	2.9 mm	0.1 in	2.54 mm	Latch Holder	Male Pin	Tin	Polyester Glass Filled	Board to Cable/Wire	Shrouded - 4 Wall	Through Hole	Square	2
Molex 0901301218	Automotive General Purpose	0.266 in	6.75 mm	15 µin	0.38 µm	Solder	Header	0.429 in	10.9 mm	All	UL94 V-0	0.1 "	2.54 mm	Brass	Black	18	0.114 in	2.9 mm	0.1 in	2.54 mm	Latch Holder	Male Pin	Tin	Polyester Glass Filled	Board to Cable/Wire	Shrouded - 4 Wall	Through Hole	Square	2			118.1 µin	3 µm		Gold
Molex 0901301224	Automotive General Purpose	0.266 in	6.75 mm	15 µin	0.38 µm	Solder	Header	0.429 in	10.9 mm	All	UL94 V-0	0.1 "	2.54 mm	Brass	Black	24	0.114 in	2.9 mm	0.1 in	2.54 mm	Latch Holder	Male Pin	Tin	Polyester Glass Filled	Board to Cable/Wire	Shrouded - 4 Wall	Through Hole	Square	2			118.1 µin	3 µm		Gold
