E2B-M12 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR PROX INDUCTIVE 2MM CYLIND
| Part | Sensor Type | Output Type | Output Type | Ingress Protection | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensing Distance | Sensing Distance | Package / Case | Indicator | Shielding | Termination Style | Operating Temperature [Min] | Operating Temperature [Max] | Response Frequency | Material - Body |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | Inductive | 3 | PNP-NC | IP67 | 10 VDC | 30 VDC | 2 mm | 0.079 in | Cylinder Threaded - M12 | LED | Shielded | Cable Leads | -25 °C | 70 °C | 1.5 kHz | Nickel-Plated Brass |
 Omron Automation and Safety | Inductive | 3-Wire NPN-NO | IP67 | 10 VDC | 30 VDC | 4 mm | 0.157 in | Cylinder Threaded - M12 | LED | Shielded | Cable Leads | -25 °C | 70 °C | 1 kHz | Nickel-Plated Brass | |
 Omron Automation and Safety | Inductive | 3-Wire NPN-NC | IP67 | 10 VDC | 30 VDC | 4 mm | 0.157 in | Cylinder Threaded - M12 | LED | Shielded | Cable Leads | -25 °C | 70 °C | 1 kHz | Nickel-Plated Brass | |
 Omron Automation and Safety | Inductive | 3-Wire NPN-NO | IP67 | 10 VDC | 30 VDC | 2 mm | 0.079 in | Cylinder Threaded - M12 | LED | Shielded | Cable Leads | -25 °C | 70 °C | 1.5 kHz | Nickel-Plated Brass | |
 Omron Automation and Safety | Inductive | 3-Wire NPN-NO | IP67 | 10 VDC | 30 VDC | 8 mm | 0.315 in | Cylinder Threaded - M12 | LED | Unshielded | Connector | -25 °C | 70 °C | 800 Hz | Nickel-Plated Brass | |
 Omron Automation and Safety | Inductive | 3 | PNP-NO | IP67 | 10 VDC | 30 VDC | 8 mm | 0.315 in | Cylinder Threaded - M12 | LED | Unshielded | Cable Leads | -25 °C | 70 °C | 800 Hz | Nickel-Plated Brass |
Omron Automation and Safety | Inductive | 3 | PNP-NO | IP67 | 10 VDC | 30 VDC | 8 mm | 0.315 in | Cylinder Threaded - M12 | LED | Unshielded | Connector | -25 °C | 70 °C | 800 Hz | Nickel-Plated Brass |
 Omron Automation and Safety | Inductive | 3 | PNP-NC | IP67 | 10 VDC | 30 VDC | 8 mm | 0.315 in | Cylinder Threaded - M12 | LED | Unshielded | Cable Leads | -25 °C | 70 °C | 800 Hz | Nickel-Plated Brass |
Omron Automation and Safety | Inductive | 3 | PNP-NC | IP67 | 10 VDC | 30 VDC | 2 mm | 0.079 in | Cylinder Threaded - M12 | LED | Shielded | Cable Leads | -25 °C | 70 °C | 1.5 kHz | Nickel-Plated Brass |
 Omron Automation and Safety | Inductive | 3 | PNP-NO | IP67 | 10 VDC | 30 VDC | 8 mm | 0.315 in | Cylinder Threaded - M12 | LED | Unshielded | Connector | -25 °C | 70 °C | 800 Hz | Nickel-Plated Brass |
