74F32 Series

Catalog

IC GATE OR

Part	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Mounting Type	Input Logic Level - Low	Logic Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Package / Case [x]	Package / Case [y]	Package / Case	Number of Circuits	Number of Inputs	Operating Temperature [Max]	Operating Temperature [Min]	Max Propagation Delay @ V, Max CL	Supplier Device Package
ON Semiconductor MC74F32MR1
ON Semiconductor 74F32SC	1 mA	20 mA	Surface Mount	0.8 V	OR Gate	4.5 V	5.5 V	0.154 in	3.9 mm	14-SOIC	4	2	70 °C	0 °C	5.6 ns
ON Semiconductor 74F32SJ	1 mA	20 mA	Surface Mount	0.8 V	OR Gate	4.5 V	5.5 V	0.209 "	5.3 mm	14-SOIC	4	2	70 °C	0 °C	5.6 ns	14-SOP
ON Semiconductor 74F32SCX	1 mA	20 mA	Surface Mount	0.8 V	OR Gate	4.5 V	5.5 V	0.154 in	3.9 mm	14-SOIC	4	2	70 °C	0 °C	5.6 ns
ON Semiconductor 74F32SCX	1 mA	20 mA	Surface Mount	0.8 V	OR Gate	4.5 V	5.5 V	0.154 in	3.9 mm	14-SOIC	4	2	70 °C	0 °C	5.6 ns
ON Semiconductor 74F32SJX	1 mA	20 mA	Surface Mount	0.8 V	OR Gate	4.5 V	5.5 V	0.209 "	5.3 mm	14-SOIC	4	2	70 °C	0 °C	5.6 ns	14-SOP
ON Semiconductor 74F32SJX	1 mA	20 mA	Surface Mount	0.8 V	OR Gate	4.5 V	5.5 V	0.209 "	5.3 mm	14-SOIC	4	2	70 °C	0 °C	5.6 ns	14-SOP
ON Semiconductor 74F32SC	1 mA	20 mA	Surface Mount	0.8 V	OR Gate	4.5 V	5.5 V	0.154 in	3.9 mm	14-SOIC	4	2	70 °C	0 °C	5.6 ns
ON Semiconductor 74F32SJ	1 mA	20 mA	Surface Mount	0.8 V	OR Gate	4.5 V	5.5 V	0.209 "	5.3 mm	14-SOIC	4	2	70 °C	0 °C	5.6 ns	14-SOP
ON Semiconductor MC74F32MR2
