0FHM0002ZXJB Series
HOLDER, MINI INLINE, RED/ORANGE WIRE
Manufacturer: Littelfuse/Commercial Vehicle Products
Catalog
HOLDER, MINI INLINE, RED/ORANGE WIRE
Key Features
• Compatible with MAXI® blade fuses up to 80 A (sold separately)
• Black UL 94 V-0 TPV body and cover create an IP67-rated dustproof and waterproof enclosure
• Heat-resistant 12 AWG GXL cross-link wire leads with orange and red insulation
• 6.575" (167 mm) lead wires with one 0.315" (8 mm) end strip and one 0.67" (17 mm) end strip
• Tin-plated copper alloy contacts
Description
AI
The MINI® FHM Series 58V Heavy-Duty In-Line Waterproof Blade Fuse Holder is ideal for adding accessory and remote circuit protection in automotive and marine applications. It features a built-in cover that connects with the fuse holder body to form a sealed enclosure. The protective enclosure meets IP67 dustproof and waterproof standards. This model of the MINI® FHM Series fuse holder (0FHM0002ZXJB) features a black TPV body and cover and 12 AWG GXL wire leads for heavy-duty applications. The lead wires, one with red insulation and one with orange insulation, are 6.575" (167mm) long and have one 0.315" (8mm) end strip and one 0.67" (17mm) end strip. The UL 94 V-0-rated fuse holder accepts up to 30-amp MINI® blade fuses (sold separately).
