307-035 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 35POS 0.156
| Part | Material - Insulation | Termination Rows | Gender | Card Type | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Contact Material | Contact Finish | Contact Type | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Color | Read Out | Number of Positions | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows | Number of Positions/Bay/Row | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Copper Alloy | Gold | Semi Bellows | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 0.25 Ám | 10 Áin | Green | Single | 35 | Solder | -40 C | 105 ░C | 1 | 35 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Gold | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Green | Dual | 70 | Solder Eyelet(s) | -40 C | 105 ░C | 35 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Tin | Semi Bellows | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Green | Dual | 70 | Solder Eyelet(s) | -40 C | 105 ░C | 35 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Copper Alloy | Gold | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Green | Dual | 70 | Wire Wrap | -40 C | 105 ░C | 35 | 2 | Card Guides | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Tin | Semi Bellows | Green | Single | 35 | Solder | -40 C | 105 ░C | 1 | 35 | |||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Copper Alloy | Gold | Semi Bellows | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.25 Ám | 10 Áin | Green | Single | 35 | Solder | -40 C | 105 ░C | 1 | 35 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Gold | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Green | Single | 35 | Wire Wrap | -40 C | 105 ░C | 1 | 35 | Card Guides | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Gold | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Green | Single | 35 | Solder | -40 C | 105 ░C | 1 | 35 | Card Guides | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Tin | Semi Bellows | Flush Mount M3 Threaded Insert Top Opening | Green | Single | 35 | Solder | -40 C | 105 ░C | 1 | 35 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Gold | Semi Bellows | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.25 Ám | 10 Áin | Green | Single | 35 | Solder Eyelet(s) | -40 C | 105 ░C | 1 | 35 |
