892-042 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 42POS 0.100
...
| Part | Termination Rows | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Material - Insulation | Number of Positions | Mounting Type | Termination | Card Type | Pitch [x] | Pitch [x] | Color | Contact Material | Number of Rows | Read Out | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Number of Positions/Bay/Row [custom] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Through Hole | Wire Wrap | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 2 | Dual | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | |||||
 EDAC Inc. | 1 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Through Hole | Solder | Non Specified - Single Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 1 | Single | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 42 | ||||
 EDAC Inc. | 1 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Through Hole | Wire Wrap | Non Specified - Single Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 1 | Single | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 42 | ||||
 EDAC Inc. | 1 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Through Hole | Solder Eyelet(s) | Non Specified - Single Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 1 | Single | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 42 | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | |
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Through Hole Right Angle | Solder | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 2 | Dual | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.25 mm | Flush Mount Top Opening Unthreaded | 0.128 " | ||
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Board Edge Straddle Mount | Solder | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 2 | Dual | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Card Extender | |
 EDAC Inc. | 1 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Through Hole | Wire Wrap | Non Specified - Single Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 1 | Single | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 42 | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | |
 EDAC Inc. | 1 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Through Hole | Solder | Non Specified - Single Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 1 | Single | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 42 | ||||
 EDAC Inc. | 1 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Through Hole Right Angle | Solder | Non Specified - Single Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 1 | Single | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 42 | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | |
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Gold | Polyphenylene Sulfide (PPS) | 42 | Through Hole | Wire Wrap | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Black | Copper Alloy | 2 | Dual | Female | 125 °C | -40 °C | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in |
