855-83 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 93POS 0.05 GOLD PCB
| Part | Contact Material | Contact Shape | Insulation Material | Material Flammability Rating | Contact Finish - Mating | Row Spacing - Mating | Row Spacing - Mating | Mounting Type | Connector Type | Number of Positions Loaded | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Number of Positions | Contact Length - Post | Contact Length - Post | Number of Rows [custom] | Contact Finish - Post | Insulation Color | Insulation Height [z] | Insulation Height [z] | Fastening Type | Termination | Pitch - Mating | Pitch - Mating | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Insulation Height | Insulation Height | Contact Length - Post [x] | Contact Length - Post [x] | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 93 | 2.4 mm | 0.094 in | 3 | Tin | Black | 4 mm | 0.157 in | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | |||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Right Angle Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 9 | 3 | Tin | Black | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | 0.174 in | 4.42 mm | 0.126 " | 3.2 mm | |||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Right Angle Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 3 | Tin | Black | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | 0.174 in | 4.42 mm | 0.126 " | 3.2 mm | 117 | |||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 36 | 2.4 mm | 0.094 in | 3 | Tin | Black | 4 mm | 0.157 in | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | |||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Right Angle Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 66 | 3 | Tin | Black | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | 0.174 in | 4.42 mm | 0.126 " | 3.2 mm | |||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Right Angle Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 114 | 3 | Tin | Black | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | 0.174 in | 4.42 mm | 0.126 " | 3.2 mm | |||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 120 | 2.4 mm | 0.094 in | 3 | Tin | Black | 4 mm | 0.157 in | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | |||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 57 | 2.4 mm | 0.094 in | 3 | Tin | Black | 4 mm | 0.157 in | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | |||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Right Angle Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 90 | 3 | Tin | Black | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | 0.174 in | 4.42 mm | 0.126 " | 3.2 mm | |||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | UL94 V-0 | Gold | 0.05 in | 1.27 mm | Right Angle Through Hole | Socket | All | -55 C | 125 °C | Female Socket | 24 | 3 | Tin | Black | Push-Pull | Solder | 1.27 mm | 0.05 in | 29.5 µin | 0.75 µm | 0.174 in | 4.42 mm | 0.126 " | 3.2 mm |
