15 Series

Catalog

FIXED IND 15UH 7.44A 15.5MOHM TH

Part	Frequency - Self Resonant	Inductance	Inductance Frequency - Test	Shielding	Current Rating (Amps)	Tolerance	Operating Temperature [Max]	Operating Temperature [Min]	Q @ Freq	Package / Case	DC Resistance (DCR) [Max]	Mounting Type	Size / Dimension [diameter]	Size / Dimension [diameter]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Type	DC Resistance (DCR)	Q @ Freq [custom]	Q @ Freq [custom]
Murata Electronics 15153C	19 MHz	15 µH	10 kHz	Unshielded	7.44 A	10 %	85 °C	-40 C	1 MHz 109	Radial Vertical Cylinder	15.5 mOhm	Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound
Murata Electronics 15683C	4 MHz	68 µH	10 kHz	Unshielded	3.33 A	10 %	85 °C	-40 C	100	Radial Vertical Cylinder	70.3 mOhm	Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound
Murata Electronics 15104C	3 MHz	100 µH	10 kHz	Unshielded	2.62 A	10 %	85 °C	-40 C	89	Radial Vertical Cylinder		Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound	110 mOhm
Murata Electronics 15103C	30 MHz	10 µH	10 kHz	Unshielded	9.01 A	10 %	85 °C	-40 C	1 MHz 112	Radial Vertical Cylinder	10.6 mOhm	Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound
Murata Electronics 15333C	8 MHz	33 µH	10 kHz	Unshielded	5.08 A	10 %	85 °C	-40 C	107	Radial Vertical Cylinder	31.2 mOhm	Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound		1 MHz
Murata Electronics 15334C	1.6 MHz	330 µH	10 kHz	Unshielded	1.71 A	10 %	85 °C	-40 C	20 kHz 68	Radial Vertical Cylinder		Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound	263 mOhm
Murata Electronics 15152C	108 MHz	1.5 µH	10 kHz	Unshielded	14.9 A	20 %	85 °C	-40 C		Radial Vertical Cylinder	3.48 mOhm	Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound		1 MHz	155
Murata Electronics 15222C	82 MHz	2.2 µH	10 kHz	Unshielded	15 A	20 %	85 °C	-40 C		Radial Vertical Cylinder		Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound	4.2 mOhm	1 MHz	127
Murata Electronics 15224C	2 MHz	220 µH	10 kHz	Unshielded	2.08 A	10 %	85 °C	-40 C		Radial Vertical Cylinder	185 mOhm	Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound		20 kHz	69
Murata Electronics 15102C	142 MHz	1 µH	10 kHz	Unshielded	16.2 A	20 %	85 °C	-40 C		Radial Vertical Cylinder	2.76 mOhm	Through Hole	16.8 mm	0.661 "	21.3 mm	0.839 in	Wirewound		1 MHz	151
