895-112 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 112POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Color | Contact Type | Contact Finish | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Gender | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Features | Mounting Type | Card Type | Number of Positions | Termination | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Card Extender | Board Edge Straddle Mount | Non Specified - Dual Edge | 112 | Solder | Copper Alloy |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | 0.156 " | 3.96 mm | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Right Angle Through Hole | Non Specified - Dual Edge | 112 | Solder | Copper Alloy | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Non Specified - Dual Edge | 112 | Wire Wrap | Copper Alloy | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | 0.156 " | 3.96 mm | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Card Extender | Board Edge Straddle Mount | Non Specified - Dual Edge | 112 | Solder | Copper Alloy | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | 0.128 " | 3.25 mm | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Non Specified - Dual Edge | 112 | Solder Eyelet(s) | Copper Alloy | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | 0.156 " | 3.96 mm | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Non Specified - Dual Edge | 112 | Solder | Copper Alloy | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | 0.128 " | 3.25 mm | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Non Specified - Dual Edge | 112 | Wire Wrap | Copper Alloy | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | 4-40 Threaded Insert Top Mount Opening | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Non Specified - Dual Edge | 112 | Wire Wrap | Copper Alloy | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | 0.128 " | 3.25 mm | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Right Angle Through Hole | Non Specified - Dual Edge | 112 | Solder | Copper Alloy | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Gold | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Dual | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Non Specified - Dual Edge | 112 | Wire Wrap | Copper Alloy |
