SFW11S Series

Catalog

CONN CIC VERT 11POS 1MM SMD

Part	Mating Cycles	Housing Color	Actuator Color	Actuator Material	Housing Material	Termination	Locking Feature	Cable End Type	Material Flammability Rating	Height Above Board [z]	Height Above Board [z]	Contact Material	Number of Positions	Pitch	Pitch	Connector/Contact Type	Contact Finish	Mounting Type	FFC, FCB Thickness	Voltage Rating	Flat Flex Type	Operating Temperature [Min]	Operating Temperature [Max]	FFC, FCB Thickness [custom]	FFC, FCB Thickness [custom]
Amphenol ICC (FCI) SFW11S-6STE1LF	10	Brown	Black	Thermoplastic Glass Filled	Glass Filled Thermoplastic	Solder	Slide Lock	Tapered	UL94 V-0	0.209 in	5.3 mm	Phosphor Bronze	11	1 mm	0.039 in	Contacts Vertical - 1 Sided	Tin	Surface Mount	0.3 mm	100 V	CIC	-55 C	85 °C
Amphenol ICC (FCI) SFW11S-2STME1LF	20	Brown		Thermoplastic Glass Filled	Glass Filled Thermoplastic	Solder			UL94 V-0	0.209 in	5.3 mm	Phosphor Bronze	11	1 mm	0.039 in	Contacts Vertical - 1 Sided	Tin	Surface Mount	0.33 mm	100 V	FFC FPC	-55 C	105 ░C
Amphenol ICC (FCI) SFW11S-2STE1LF	20	Brown	Black	Thermoplastic Glass Filled	Glass Filled Thermoplastic	Solder	Slide Lock	Straight Tapered	UL94 V-0	0.209 in	5.3 mm	Phosphor Bronze	11	1 mm	0.039 in	Contacts Vertical - 1 Sided	Tin	Surface Mount		100 V	FFC FPC	-55 C	105 ░C	0.3 mm	0.33 mm
Amphenol ICC (FCI) SFW11S-2STAE1LF	20	Brown	Black	Thermoplastic Glass Filled	Glass Filled Thermoplastic	Solder	Slide Lock	Tapered	UL94 V-0	0.209 in	5.3 mm	Phosphor Bronze	11	1 mm	0.039 in	Contacts Vertical - 1 Sided	Gold	Surface Mount	0.3 mm	100 V	FPC	-55 C	85 °C
