842-054 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 54POS 0.100
| Part | Card Type | Contact Finish Thickness | Contact Finish Thickness | Termination | Color | Material - Insulation | Contact Type | Read Out | Mounting Type | Termination Rows | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Flange Feature | Gender | Number of Positions | Contact Finish | Number of Positions/Bay/Row | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Wire Wrap | Green | Diallyl Phthalate (DAP) | Cantilever | Single | Through Hole | 1 | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 4-40 Flush Mount Threaded Insert Top Opening | Female | 54 | Gold | 54 | Copper Alloy | |||||
 EDAC Inc. | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Solder | Green | Diallyl Phthalate (DAP) | Cantilever | Single | Right Angle Through Hole | 1 | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Flush Mount Top Opening Unthreaded | Female | 54 | Gold | 54 | Copper Alloy | 3.25 mm | 0.128 " | |||
 EDAC Inc. | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Wire Wrap | Green | Diallyl Phthalate (DAP) | Cantilever | Single | Through Hole | 1 | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 4-40 Flush Mount Threaded Insert Top Opening | Female | 54 | Gold | 54 | Copper Alloy | |||||
 EDAC Inc. | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Wire Wrap | Green | Diallyl Phthalate (DAP) | Cantilever | Dual | Through Hole | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Floating Bobbin Flush Mount | Female | 54 | Gold | 27 | Copper Alloy | 2.95 mm | 0.116 " | 2 | 2 | |||
 EDAC Inc. | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Solder | Green | Diallyl Phthalate (DAP) | Cantilever | Dual | Right Angle Through Hole | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Flush Mount M3 Threaded Insert Top Opening | Female | 54 | Gold | 27 | Copper Alloy | 2 | 2 | |||||
 EDAC Inc. | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Solder | Green | Diallyl Phthalate (DAP) | Cantilever | Dual | Right Angle Through Hole | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 4-40 Flush Mount Threaded Insert Top Opening | Female | 54 | Gold | 27 | Copper Alloy | 2 | 2 | |||||
 EDAC Inc. | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Solder | Green | Diallyl Phthalate (DAP) | Cantilever | Dual | Board Edge Straddle Mount | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Female | 54 | Gold | 27 | Copper Alloy | 2 | 2 | Card Extender | |||||
 EDAC Inc. | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Solder | Green | Diallyl Phthalate (DAP) | Cantilever | Dual | Through Hole | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Flush Mount Top Opening Unthreaded | Female | 54 | Gold | 27 | Copper Alloy | 3.25 mm | 0.128 " | 2 | 2 | |||
 EDAC Inc. | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Solder | Green | Diallyl Phthalate (DAP) | Cantilever | Dual | Through Hole | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Flush Mount M3 Threaded Insert Top Opening | Female | 54 | Gold | 27 | Copper Alloy | 2 | 2 | |||||
 EDAC Inc. | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Solder | Green | Diallyl Phthalate (DAP) | Cantilever | Single | Through Hole | 1 | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Flush Mount M3 Threaded Insert Top Opening | Female | 54 | Gold | 54 | Copper Alloy |
