857-080 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 80POS 0.156
| Part | Number of Positions | Color | Termination Rows | Pitch [x] | Pitch [x] | Gender | Mounting Type | Contact Type | Number of Positions/Bay/Row [custom] | Contact Material | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Read Out | Card Type | Number of Rows | Termination | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Through Hole | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Non Specified - Dual Edge | 2 | Solder | 0.116 in | Floating Bobbin Flush Mount | 2.95 mm | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Tin | |||||
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Through Hole Right Angle | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | Non Specified - Dual Edge | 2 | Solder | 0.116 in | Floating Bobbin Flush Mount | 2.95 mm | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Gold | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Through Hole | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Non Specified - Dual Edge | 2 | Solder | Side Mount Opening Unthreaded | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Tin | 3.25 mm | 0.128 in | |||||
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Board Edge Straddle Mount | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Non Specified - Dual Edge | 2 | Solder | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Tin | Card Extender | ||||
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Through Hole | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Non Specified - Dual Edge | 2 | Wire Wrap | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Tin | |||||
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Through Hole Right Angle | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | Non Specified - Dual Edge | 2 | Solder | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Gold | 10 Áin | 0.25 Ám | ||||||
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Through Hole | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Non Specified - Dual Edge | 2 | Solder | Flush Mount M3 Threaded Insert Top Opening | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Tin | |||||||
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Board Edge Straddle Mount | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Non Specified - Dual Edge | 2 | Solder | 0.116 in | Floating Bobbin Flush Mount | 2.95 mm | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Gold | 10 Áin | 0.25 Ám | Card Extender | ||
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Through Hole Right Angle | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | Non Specified - Dual Edge | 2 | Solder | 0.116 in | Floating Bobbin Flush Mount | 2.95 mm | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Gold | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | 80 | Black | 2 | 0.156 in | 3.96 mm | Female | Through Hole | Semi Bellows | 40 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Non Specified - Dual Edge | 2 | Solder | Side Mount Opening Unthreaded | Polyphenylene Sulfide (PPS) | 125 °C | -40 °C | Tin | 3.25 mm | 0.128 in |
