TPS7A21-Q1 Series

Automotive, 500mA, low-noise ultra-low-IQ high-PSRR low-dropout (LDO) voltage regulator

Catalog

Automotive, 500mA, low-noise ultra-low-IQ high-PSRR low-dropout (LDO) voltage regulator

Part	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Grade	Qualification	Package / Case	Voltage Dropout (Max) [Max]	Supplier Device Package	Output Type	Current - Quiescent (Iq)	Number of Regulators	Control Features	Output Configuration	Protection Features	PSRR [Max]	PSRR	PSRR [Min]	Voltage - Output (Min/Fixed)	Current - Output	Voltage - Input (Max) [Max]	Current - Supply (Max) [Max]
Texas Instruments TPS7A2110PQWDRBRQ1	150 °C	-40 °C	Surface Mount Wettable Flank	Automotive	AEC-Q100	8-VDFN Exposed Pad	0.605 V	8-SON (3x3)	1.81 mOhm	15 µA	1	Current Limit Enable	Positive	Over Current Over Temperature Under Voltage Lockout (UVLO)	90 dB	91 dB	50 dB	1 V	500 mA	6 V
Texas Instruments TPS7A2128PQWDRBRQ1	150 °C	-40 °C	Surface Mount Wettable Flank	Automotive	AEC-Q100	8-VDFN Exposed Pad	0.265 V	8-SON (3x3)	1.81 mOhm	15 µA	1	Current Limit Enable	Positive	Over Current Over Temperature Under Voltage Lockout (UVLO)	90 dB	91 dB	50 dB	2.8 V	500 mA	6 V
Texas Instruments TPS7A2150PQWDRBRQ1	125 °C	-40 °C	Surface Mount Wettable Flank	Automotive	AEC-Q100	8-VDFN Exposed Pad	0.355 V	8-SON (3x3)	1.81 mOhm	18 µA	1	Current Limit Enable	Positive	Over Current Over Temperature Under Voltage Lockout (UVLO)	90 dB	91 dB	50 dB	5 V	500 mA	6 V	3.5 mA
Texas Instruments TPS7A2115PQWDRBRQ1	125 °C	-40 °C	Surface Mount Wettable Flank	Automotive	AEC-Q100	8-VDFN Exposed Pad	0.355 V	8-SON (3x3)	1.81 mOhm	18 µA	1	Current Limit Enable Soft Start	Positive	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	90 dB	91 dB	50 dB	1.5 V	500 mA	6 V	3.5 mA

Catalog

Automotive, 500mA, low-noise ultra-low-IQ high-PSRR low-dropout (LDO) voltage regulator

Key Features

• AEC-Q100 qualified for automotive applications:Temperature grade 1: –40°C to +125°CJunction temperature: –40°C to +150°CVery low IQ: 6.5µAInput voltage range: 2.0V to 6.0VOutput voltage range: 0.8V to 5.5V (50mV steps)High PSRR: 91dB at 1kHzLow output voltage noise: 7.7µVRMSLow dropout:265mV (maximum) at 500mA (2.5V VOUT)Smart EN pulldownOutput voltage tolerance: ±1% over temperatureSupports a wide range of ceramic capacitors:1µF to 200µFPackage:3mm × 3mm wettable flank VSON2mm × 2mm wettable flank WSON2mm × 2mm WSON (Advance Information)AEC-Q100 qualified for automotive applications:Temperature grade 1: –40°C to +125°CJunction temperature: –40°C to +150°CVery low IQ: 6.5µAInput voltage range: 2.0V to 6.0VOutput voltage range: 0.8V to 5.5V (50mV steps)High PSRR: 91dB at 1kHzLow output voltage noise: 7.7µVRMSLow dropout:265mV (maximum) at 500mA (2.5V VOUT)Smart EN pulldownOutput voltage tolerance: ±1% over temperatureSupports a wide range of ceramic capacitors:1µF to 200µFPackage:3mm × 3mm wettable flank VSON2mm × 2mm wettable flank WSON2mm × 2mm WSON (Advance Information)

Description

The TPS7A21-Q1 is a small, low-dropout (LDO) linear voltage regulator that sources 500mA of output current. The device provides low noise, high PSRR, and excellent load and line transient performance to meet the requirements of RF and other sensitive analog circuits in automotive applications. Innovative design techniques result in low-noise performance without the addition of an external noise bypass capacitor. The TPS7A21-Q1 low quiescent current is a good choice for low-power systems. The 2.0V to 6.0V input voltage range and 0.8V to 5.5V output voltage range support a variety of system requirements. An internal soft-start circuit helps control inrush current, thus minimizing the input voltage drop during start-up. The LDO is stable with small ceramic capacitors, allowing for a small overall solution size. A smart enable input circuit with an internally controlled pulldown resistor keeps the LDO disabled even when the EN pin is unconnected. This circuit also helps eliminate external components that are otherwise required to pull down the EN input. The TPS7A21-Q1 is a small, low-dropout (LDO) linear voltage regulator that sources 500mA of output current. The device provides low noise, high PSRR, and excellent load and line transient performance to meet the requirements of RF and other sensitive analog circuits in automotive applications. Innovative design techniques result in low-noise performance without the addition of an external noise bypass capacitor. The TPS7A21-Q1 low quiescent current is a good choice for low-power systems. The 2.0V to 6.0V input voltage range and 0.8V to 5.5V output voltage range support a variety of system requirements. An internal soft-start circuit helps control inrush current, thus minimizing the input voltage drop during start-up. The LDO is stable with small ceramic capacitors, allowing for a small overall solution size. A smart enable input circuit with an internally controlled pulldown resistor keeps the LDO disabled even when the EN pin is unconnected. This circuit also helps eliminate external components that are otherwise required to pull down the EN input.
