RFAATNC Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
RF / COAXIAL ADAPTER, TNC, PLUG, TNC, PLUG, STRAIGHT ADAPTER, 50 OHM
| Part | Body Material | Dielectric Material | Center Contact Material | Mating Cycles | Operating Temperature [Min] | Operating Temperature [Max] | Impedance | Conversion Type | Convert To (Adapter End) | Style | Center Gender | Adapter Type | Mounting Type | Frequency - Max [Max] | Adapter Series | Convert From (Adapter End) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | Stainless Steel | Polyetherimide (PEI) Polytetrafluoroethylene (PTFE) | Beryllium Copper | 500 | -65 ░C | 165 °C | 50 Ohms | Same Series | TNC Plug Male Pin | Straight | Male to Male | Plug to Plug | Free Hanging (In-Line) | 11 GHz | TNC to TNC | |
 BULGIN LIMITED | Stainless Steel | Polyetherimide (PEI) Polytetrafluoroethylene (PTFE) | Beryllium Copper | 500 | -65 ░C | 165 °C | 50 Ohms | Same Series | Female Socket TNC Jack | Straight | Female to Female | Jack to Jack | Free Hanging (In-Line) | 11 GHz | TNC to TNC | Female Socket TNC Jack |
BULGIN LIMITED | Stainless Steel | Polyetherimide (PEI) Polytetrafluoroethylene (PTFE) | Beryllium Copper | 500 | -65 ░C | 165 °C | 50 Ohms | Same Series | TNC Plug Male Pin | Straight | Plug to Jack | Free Hanging (In-Line) | 11 GHz | TNC to TNC | Female Socket TNC Jack | |
BULGIN LIMITED | Stainless Steel | Polyetherimide (PEI) Polytetrafluoroethylene (PTFE) | Beryllium Copper | 500 | -65 ░C | 165 °C | 50 Ohms | Between Series | TNC Plug Male Pin | Straight | Plug to Jack | Free Hanging (In-Line) | 11 GHz | N to TNC | Female Socket N Jack |
