387-036 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 36POS 0.156
...
| Part | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Positions | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Mounting Type | Material - Insulation | Color | Pitch [x] | Pitch [x] | Read Out | Number of Positions/Bay/Row [custom] | Termination | Termination Rows | Contact Type | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Contact Material | Gender | Flange Feature | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 36 | 0.156 in | Top Mount Opening Unthreaded | 3.96 mm | Through Hole | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Dual | 18 | Wire Wrap | 2 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | |||
 EDAC Inc. | 1 | 10 Áin | 0.25 Ám | Non Specified - Single Edge | 36 | 0.156 in | Top Mount Opening Unthreaded | 3.96 mm | Through Hole | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Single | 36 | Solder | 1 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | |||
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 36 | 4-40 Threaded Insert Top Mount Opening | Through Hole Right Angle | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Dual | 18 | Wire Wrap | 2 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | |||||
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 36 | 0.156 in | Flush Mount Top Opening Unthreaded | 3.96 mm | Through Hole Right Angle | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Dual | 18 | Wire Wrap | 2 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | |||
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 36 | Through Hole | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Dual | 18 | Solder | 2 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | 3.25 mm | 0.128 in | ||||
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 36 | 0.116 in | Floating Bobbin Top Mount Opening | 2.95 mm | Through Hole | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Dual | 18 | Solder | 2 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | |||
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 36 | 4-40 Threaded Insert Top Mount Opening | Through Hole | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Dual | 18 | Solder | 2 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | |||||
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 36 | 4-40 Threaded Insert Top Mount Opening | Through Hole | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Dual | 18 | Wire Wrap | 2 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | |||||
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 36 | 0.156 in | Flush Mount Top Opening Unthreaded | 3.96 mm | Board Edge Straddle Mount | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Dual | 18 | Solder | 2 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | Card Extender | ||
 EDAC Inc. | 2 | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 36 | M3 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | Polyester Thermoplastic | Black | 0.156 in | 3.96 mm | Dual | 18 | Solder | 2 | Cantilever | Gold | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | Female | Card Extender |
