837-058 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 58POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Pitch | Pitch | Features | Flange Feature [diameter] | Flange Feature [diameter] | Color | Number of Positions | Number of Rows [custom] | Read Out | Mounting Type | Card Type | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Gender | Contact Finish Thickness | Contact Finish Thickness | Termination | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Contact Material | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | Card Extender | 0.156 " | 3.96 mm | Green | 58 | 2 | Dual | Board Edge Straddle Mount | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | 0.128 " | 3.25 mm | Green | 58 | 2 | Dual | Through Hole | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | Green | 58 | 2 | Dual | Through Hole | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | Card Extender | 0.128 " | 3.25 mm | Green | 58 | 2 | Dual | Board Edge Straddle Mount | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | Flush Mount Side Opening Unthreaded |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | 0.156 " | 3.96 mm | Green | 58 | 2 | Dual | Through Hole | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | Card Extender | Green | 58 | 2 | Dual | Board Edge Straddle Mount | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | Card Extender | 0.128 " | 3.25 mm | Green | 58 | 2 | Dual | Board Edge Straddle Mount | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | Flush Mount Side Opening Unthreaded |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | Green | 58 | 2 | Dual | Through Hole | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | 0.156 " | 3.96 mm | Green | 58 | 2 | Dual | Through Hole | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.96 mm | 0.156 in | Card Extender | Green | 58 | 2 | Dual | Board Edge Straddle Mount | Non Specified - Dual Edge | Cantilever | 125 °C | -40 C | 29 | Female | 0.25 Ám | 10 Áin | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening |
